Help CenterSliding Table Saw
Related Products
Facotry Table Saw
Function Characteristics:
Main Specification And Technology Parameter
Model |
MJQ6128 |
MJQ6132CA |
Max sawing length |
2800mm |
3220mm |
Max sawing thickness |
65mm |
65mm |
45°tilting max sawing thickness |
55mm |
55mm |
Main saw blade dimension (max) |
305x30mm |
Φ305×Φ30mm |
Groove- saw blade dimension |
120x22mm |
Φ120×Φ22mm |
Main saw arbor rotary speed |
4000,5000r/min |
4000,5000r/min |
Groove- saw arbor rotary speed |
8600r/min |
8600r/min |
Main saw motor power / Voltage frequency |
5.5kw(7.4HP)/380V50HZ |
5.5kw(7.4HP) /380V 50HZ |
Groove-saw motor power / Voltage frequency |
0.75KW(1HP)/380V50Hz |
0.75kw(1HP) /380V 50HZ |
Weight of machine |
800KG |
1000kg |
Overall dimension(L×W×H) |
3200*3080*1150mm |
3450×3080×1150mm |
Dust-collecting mouth external diameter |
100mm |
Φ100mm(4") |
Our product is improving. When the external form and parameter changes, please refer to the material object. We will not inform you especially.
If you have any questions,you can contact us on skype or e-mail to me:
Contact way:
Skype:VL2012520
Mobile :+86 13823402897
whatsapp:0086 13823402897
wechat:469328503
Send Inquiry to This Supplier
