Help CenterSolid Wood Panel Saw
Related Products
Facotry Table Saw
Function Characteristics:
Main Specification And Technology Parameter
Model |
MJQ6128 |
MJQ6132CA |
Max sawing length |
2800mm |
3220mm |
Max sawing thickness |
65mm |
65mm |
45°tilting max sawing thickness |
55mm |
55mm |
Main saw blade dimension (max) |
305x30mm |
Φ305×Φ30mm |
Groove- saw blade dimension |
120x22mm |
Φ120×Φ22mm |
Main saw arbor rotary speed |
4000,5000r/min |
4000,5000r/min |
Groove- saw arbor rotary speed |
8600r/min |
8600r/min |
Main saw motor power / Voltage frequency |
5.5kw(7.4HP)/380V50HZ |
5.5kw(7.4HP) /380V 50HZ |
Groove-saw motor power / Voltage frequency |
0.75KW(1HP)/380V50Hz |
0.75kw(1HP) /380V 50HZ |
Weight of machine |
800KG |
1000kg |
Overall dimension(L×W×H) |
3200*3080*1150mm |
3450×3080×1150mm |
Dust-collecting mouth external diameter |
100mm |
Φ100mm(4") |
Our product is improving. When the external form and parameter changes, please refer to the material object. We will not inform you especially.
