Window/floor Mortise and Tenon Machine

Window/floor Mortise and Tenon Machine thumbnail-1
Window/floor Mortise and Tenon Machine thumbnail-2
Window/floor Mortise and Tenon Machine thumbnail-3
Window/floor Mortise and Tenon Machine photo-1
Window/floor Mortise and Tenon Machine photo-2
Window/floor Mortise and Tenon Machine photo-3
US$ 2,400 - 3,500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Application:
woodworking
Automatic Grade:
Semi-Automatic
Contact Supplier Request Quote Chat Now
Foshan Xinnianhua Machinery Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shunde/Guangzhou/Foshan
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application woodworking
Automatic Grade Semi-Automatic
Motor Speed 9700/7500/5200 r/mins
Max Processing Width 3200mm
Max Processing Thickness 5mm
Drill Diameter 35 mm
Place of Origin Guangdong, China
Brand Name Xinnianhua/sunnywei
Model Number MS365
Voltage 380V/220V
Power(W) 5.5KW
Dimension(L*W*H) 2800*750*1200
Certification CQC
After-sales Service Provided Overseas service center available

Window/floor mortise and tenon machine



1.Variety of wood board milling concave-convex tenon slot ,long slot finishing.

2.Pneumatic pressing materials function ,high precision ,decrease hard word ,and high efficiency



Main Technology Dates
Model

MS365

Slide worktable max distance

2800mm

Max processing length

2800mm

Max working width

5mm

Max working deept





5mm

Dia.of cutter spindle

Φ35mm

Rotary speed of cutter spindle

9700/7500/5200 r/min

Main spindle lifting height

100mm

Install power

5.5kw/ 380V 50HZ

Consumption of pressure

0.6mpa

Weight of machine





560kg

Overall dimensions(L×W×H)

2800×750×1200mm


Our product is improving. When the external form and parameter changes, please refer to the material object. We will not inform you especially.
