AOS-50 heat transfer oil mold temperature controller machine for industry
- 500 Set / Sets per Month
- Shenzhen
- T/T Credit Card
- Oil Type Hot runner mold temperature controller/Injection molding temperature control system
- injection machine water-heating high temperature mold temperature controller
- Oil Type Hot runner mold temperature controller/Injection molding temperature control system
- Oil Type Mold Temperature Controller
- Water Type Mould Water Heating Plastic Injection Mold Temperature Controller
- Water Heating Mold/Mould Temperature Controller MTC for Plastic Injection
Product Details
Condition: | New | Type: | Oil Temperature Machine | Application: | plastic injection mould,roller,reaction kettle, plate |
Place of Origin: | Guangdong, China | Brand Name: | AODE | Model Number: | AOS-50 |
Temperature Range: | 25℃~180℃ | Temperature Control Accuracy: | PID±1℃ | Dimension(L*W*H): | 1150*500*1250mm |
Weight: | 120kg | Internal Piping Size: | 1/2 | Voltage: | 3N380V50HZ |
Power(W): | 24KW | Certification: | CE and ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
AOS-50 heat transfer oil mold temperature controller machine for industry Quick Detail:
Temp. Control accuracy:PID±1℃
Temp. Control range: Inlet water temperature+25℃-180℃
Certification:CE & ROHS
Controller:microcomputer
Heating capacity: 24KW
Maximum power consumption: 27.75KW
Alarm function:Excess temperature, open phase, oil starvation, overloading, reverse turn
AOS-50 heat transfer oil mold temperature controller machine for industry Description:
Explosion-proof equipment(optional)
Air blowing and return water function(optional)
Thermometer for return water
Automatic air-exhausting function after startup
Switchover of heating power
Instant cooling shut-down function(optional)
RS485 communication function for automated management(optional)
BY-PASS pressure release loop for hot water
Customizable multi-point temperature control unit
Customizable horsepower and heating power of water pump
Brands OMRON, FUJI, TE, LG, MOELLER, ABB, and WEST for electric appliances
Range of temperature control: +15℃-180℃for incoming water
Stainless steel integrated pipelines for less pipe resistance and rust
Control mode: imported microcomputer or PLC(optional)
Perfect safety protection, fault display, easy repair and maintenance even free of professionals
AOS-50 heat transfer oil mold temperature controller machine for industry Specifications:
ITEM | UNIT | AOS-50 |
Temp control range | ℃ | Inlet water temperature +25℃-180℃ |
Temp control accuracy | ℃ | PID±1℃ |
Power supply |
| AC3N380V 50HZ +E(5M) |
Heat transfer medium |
| Conduction oil |
Cooling method |
| Indirect Cooling |
Heating capacity | KW | 24 |
Max. power consumption | KW | 27.75 |
Horsepower of pump | hp | 5 |
Working flow of pump | L/min | 240 |
Working pressure of pump | Kg/cm2 | 2.6 |
Oil reserve | liter | 40 |
Alarm function |
| excess temperature/Open phase/oil starvation/ overloading/reverse turn |
Cooling water pipe | inch | 1/2 |
Circulating water pipe | inch | 3/4×4 |
Size(L×W×H) | mm | 1150×500×1250 |
AODE Factory service hotline: +86-13682516936
Our Customers service hotline: +86-13682516936
AODE Certification Service Online: +86-13682516936
AODE Spirit Service Online: +86-13682516936
AODE Components Service Online: +86-13682516936
Applications ervice Online: +86-13682516936
Successful Projects Service Online: +86-13682516936
AODE Service Service Online: +86-13682516936
Aode machinery provides customers with professional and high-speed before sale, sale, after-sales service,service details are as follows;
1, Provides customers with a full range of technical support and technical training anytime, anywhere.
2, The whole equipment free one-year warranty and lifetime maintenance.
3, Provides customers with the thoughtful usage of maintenance tips and perfect after-sales service management system.
4, Received after-sales requirement, technicians will arrive the user factory within 24 hours and handle the equipment failure immediately.
Terms and Conditions:
1.Trade terms: EXW, FOB, CIF and so on
2.Delivery Time: Within 20-25 days after received deposit
3.Payment Terms:40% T/T in advance, 60% balance before delivery
4.Shipping port: Shenzhen, Tianjin or Shanghai
5. Package: Wooden case
