MJQ113B Circular Saw Wood Cutting Machine

FOB Price

US$ 2,000 - 3,000 / Set

2 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Circular Saw, circular saw, wood cutting
Use	Other, Woodworking, woodworking, wood cutting	Style	Horizontal
Place of Origin	Guangdong, China	Brand Name	Sunnywei or Xinnianhua
Model Number	MJQ113B	Usage	Woodworking
Voltage	380v 50hz 3ph	Power(W)	4/5.5kw
Dimension(LWH)	215023001066mm	Weight	395kg
Certification	CQC

circular saw machine
1.max sawing length:2000mm
2.main rotary speed:4100r/min
3.adjustable angle:90-45degree
4.wood cutting

MJQ113B circular saw wood cutting machine

USE OF THE MACHINE

The machine is applied for processing the wood that require vertical horizontal or saw at different angle.Easy and safe to operate,

working exactly,it is suitable for processing furniture and speaker box etc.

MAIN SPECIFICATION AND TECHNOLOGY PARAMETER

Model	MJQ113B
Max sawing length	2000mm
Max sawing thickness (90°)	70mm
Max sawing thickness(45°)	50mm
Max saw blade dimension	Φ305×Φ30mm
Saw blade tilting angle	90°-45°
Main spindle rotary speed	4100 r/min
Motor power / Voltage frequency	4kw(5.5HP) / 380V 50Hz
Weight of machine	395kg
Overall dimensions (L×W×H)	2150×2300×1066mm

Strengths:

1.high quality of the spindle bearing

2.stable running,easy to operate,working exactly

3.the error of straightness on whole distance of travel is less than 0.15mm.

4.accurately process

5.nece-sarry precise panel saw to process panel funiture
