Specifications
table saw circular1.with excellent parts
table can tilting 45degree
3.motor add overload protection
4.quality parts
USE OF THE MACHINE
The machine is applied for processing the wood that require vertical horizontal or saw at different angle.Easy and safe to operate,working exactly,it is suitable for processing furniture and speaker box etc.
Table saw circular for woodworking
MAIN SPECIFICATION AND TECHNOLOGY PARAMETER
Model | MJ105 |
Max sawing width | 400mm |
Max sawing height | 80mm |
Lift height of worktable | 90mm |
Adjustable angle of worktable | 0°-45° |
Min size of saw blade (diameter × spindle) | Φ305×Φ25.4 |
Main spindle rotary speed | 4260r/min |
Motor power/Voltage frequency | 3kw(4HP) / 380V 50Hz |
Weight of machine | 150kg |
Overall dimensions (L×W×H) | 940×930×910mm |
Strengths:
1.high quality of the spindle bearing
2.stable running,easy to operate,working exactly
3.the error of straightness on whole distance of travel is less than 0.15mm.
4.accurately process
5.nece-sarry precise panel saw to process panel funiture
