Best woodworking electric saw machine
Usd and applicability range of the machine
The machine belong to light type series of precision panel saw, it absorb ingeniously the advantage of panel saw , meanwhile it has advantage of little volume,multi-function ,use in semi-precise cutting material of nature solid wood ,MDF board ,veneer ,flake-board, meanwhile may cut plastic board ,bakelite,PVC,aluminum alloy etc, also process panel material at longitudinal ,transverse ,bevel direction , main saw blade may process panel material at 45º direction ,easily operate ,accurately process ,it is necessary precise panel saw to process furniture.
Main technology dates
Max sawing length | 1600mm |
Max sawing thickness (90°) | 70mm |
Max sawing thickness(45°) | 50mm |
Max saw blade dimension | Φ305×Φ30mm |
Saw blade tilting angle | 0°-45° |
Main spindle rotary speed | 4100r/min |
Motor power / Voltage frequency | 5.5kw(5.5HP) 380V 50Hz |
Weight of machine | 365kg |
Overall dimensions (L×W×H) | 1600×914×1066mm |
If you have any questions,you can contact us on skype or e-mail to me:
Contact way:
Skype:VL2012520
Mobile :+86 18927780739
