Product Name: Automatic multihead combination weigher for screw feeding
Model: JW-A14
1. Application
* It is suitable for weighing the sticky material, such as meat.
2. Features
* Arc-shaped machine frame.
* Integral machine frame with middle standing increases the stability of machine frame and
improves performance.
* Special actuator design makes the new hoppers work better and read weight figure quickly.
* Screw feeding insteads of vibrating feeding, suits for sticky material.
* Scraper hopper design solves problems of material sticking on the hoppers.
* 60 discharging chute discharge makes sure products discharge smoothly.
3. Mechanical Character
* Second generation modular control system.
* Screw feeding insteads of vibrating feeding, suits for sticky material.
* Scraper hopper design to solve problems of sticking on the hoppers.
* 60 discharge chute will discharge material smoothly.
4. Technical Specification
| Model | JW-A14 |
| Identify Code | A14-2-3 |
| Single Weighing Range | 10-1000g |
| Accuracy | X(0.5) |
| Max Speed | 60 P/M |
| Hopper Volume | 1.6 L |
| Control Panel | 9.7 '' Touch Screen |
| Options | Dimple Plate /Timing Hopper/Printer/Reject Device |
| Driving System | Step Motor |
| Power Requirement | 220V/1500W/50/60HZ/10A |
| Packing Dimension(mm) | 1700(L)X1200(W)X1300(H) |
| Gross Weight | 500kg |
5. Deminsion
