PTC heating core is a new kind heater in the market.It is fixed by a pair of metel electrodes wiith leads on both sides of PTC elements. Metal electrode having assemblied a pair of belt fuse in two flanks side of average PTC component, Yellow insulative film, Structure are still simple in the metal electrode outward appearance on envelop.
The singple-structure heater gives our constant-temperture heat and does not need any additional temperatureapplications.
PTC heating element has many advantage as follow:
1. simple structure heater gives out constant-temperature heat and not need any additional temperature applications.
2. safety
3. give out heat continuously and keep stady power
4. It is used in a large range of voltage
5. longer service time
6. Higher reliability
7. dimension is nimble various, may need according to customer reality book make various type specifications.
PTC heating element is used for hair permanent clamp ,hair curler,face sauna,,electric mosquito killer,heat preservation plate,physical therapy apparatus,hot melt glue gun and so on.
Product model :
|
name of the product
|
length | width | thickness | temperature | voltage |
the length of the cable |
|
ptc heating element |
70mm | 13mm | 3.1mm |
275 Centidegree |
220V/110V |
150mm(length as per your request) |
| ptc heating element |
70mm | 12mm | 3.1mm |
255 Centidegree |
220V/110V |
155mm(length as per your request) |
|
ptc heating element |
64mm | 12mm | 2.9mm |
230 Centidegree |
220V/110V |
250mm(length as per your request) |
| ptc heating element |
52mm | 12mm | 3.1mm |
180 Centidegree |
220V/110V |
150mm(length as per your request) |
| ptc heating element |
35mm | 10mm | 2.8mm |
220 Centidegree |
220V/110V |
55mm(length as per your request) |
|
ptc heating element |
24mm | 8mm | 3.1mm |
160 Centidegree |
220V/110V |
120mm(length as per your request) |
|
ptc heating element |
24mm | 6mm | 2.6mm |
150 Centidegree |
220V/110V |
125mm(length as per your request) |
Above information all could customized the orders as per your specifications.
The operating voltage could do it from 12V to 230V.
The temperature from 100 Centidegree to 290 Centidegree
Our Insulated voltage: 3750V/1 second.
the length, the width, the thickness all can customized basic on you.
