Help CenterCheap 44 Keys 5050 Led Strip Led Controller
Related Products
-
24 Keys LED Strip Infrared Led ControllerUS$ 2 - 4MOQ: 5 Pieces -
Hot Sale Rgb Digital ts 1000 Led ControllerUS$ 20 - 50MOQ: 5 Pieces
-
CE&Rohs Mutil-fuction RGB Software for Led Card ControllerUS$ 20 - 50MOQ: 5 Pieces
-
Professional RGB LED of Display Led Control CardUS$ 20 - 50MOQ: 5 Pieces
-
5V-24V Professional RGB LED Pixel ControllerUS$ 20 - 50MOQ: 5 Pieces
Specifications
led strip led controller1. IR wireless;
2. Working voltage:12V/24V
3. Power: 12V*6A=72W
4.CE&RoHS
led strip led controller
Description:
Professional and high quality driver allows you to remotely control lighting based on LED products such as tapes. It has 44 programs (e.g quickly flashing colors, slow change of colors). It enables wireless change of colors, programs and light intensity. It is also possible to set any color (by mixing the primary colors).
Technical Dscription:
Working temperature |
-20-60°C |
Supply voltage |
DC5V, 12V,24V optional |
0utput |
Three CMOS Open-drain output |
Connecting mode |
common anode/cathode optional |
Certificates |
CE&RoHS |
Number of programs |
44 |
Remote control type |
IR |
| Voltage Voltage | DC5V/12V/24V |
Static power consumption |
<1W |
Output current |
<2A(each channel) |
Output power |
5V:<30W, 12V:<72W, 24V:<144W |
More other controllers items information:
Direction for use:
1.Connect the load wire at first, following by the power wire; Please ensure short circuit can not occur between connecting wire before you turn on the power.
2.Operation: you will receive infrared remote control in front of infrared receiver to ensure that there is no barrier between the remote controller and receiver.
The key press functions are shown in the table as below (in accordance with the key position order)
Brightness rise(a total of eight grading) |
Brightness fall(a total of eight grading) |
Pause/Run |
On/Off |
Static red |
Static green |
Static blue |
Static white |
Static orange |
Static light green |
Static dark blue |
Static milk white |
Static dark yellow |
Static cyan |
Static lyons blue |
Static white pink |
Static yellow |
Static light blue |
Static purple |
Static green-white |
Static light yellow |
Static sky blue |
Static brown |
Static blue white |
Increase red |
Increase green |
Increase blue |
Speed up |
Decrease red |
Decrease green |
Decrease blue |
Speed-down |
DIY key1 |
DIY key2 |
DIY key3 |
Automatic change |
DIY key4 |
DIY key5 |
DIY key6 |
Flash on and off |
3 color jumpy change |
7 color jumpy change |
3 color fade change |
7 color fade change |
Notes:
1. Supply voltage of this product is DC12V~24V, never connect to others or AC220V.
2. Before using the infrared remote, the insulating film should removed.
3. Lead wire should be connected correctly according to grade that connecting diagram offers.
4. This product is not to overload;
5. Warranty of this product is two year, but exclude the artificial situation of damaged or overload working
