Specifications
rotary kiln
1.ISO9001:2008
2.Lifetime Service
3.Stable&Adjustable Temperature
4.Energy saving
Rotary kiln is ideal for calcining high-grade cement in cement plants. It is also commonly used in the production process of catalytic agent, molecular sieve and zinc oxide, etc. As a result, you can find a rotary kiln in variety of industries, like steel annealing and nonferrous smelting industries, metallurgy and chemistry fields, and building industries, and more. Rotary kiln is a commonly used building material machine, which is also called a rotary calcine kiln, cement kiln, lime rotary kiln and ceramisite rotary kiln, classifying by material properties.
The technical characteristics of lime kiln
1. lime kiln advanced structure, low loss vertical preheater can effectively improve the preheating effect of preheated limestone kilndecomposition rate of up to 20-25%, and the direct use of 10-15mm fine grade limestone ;
2. Reliable rotary lime kiln combined scales sealed at both ends. The leakage coefficient is less than 10% use of composite refractory material to reduce radiant heat loss;
3.lime kiln filled, can be partitioned ventilated round or square vertical cooler, resorted lime cooler temperature at 800 °C about, easy to transport, storage, and secondary air into the kiln will be heated to above 7000 °C
The main technical parameters
specifications |
Production capacity |
Motor model |
power |
reducer |
Total weight |
φ1.2×12 |
1.9-2.5 |
Y160L-6 |
11 |
ZQ50 |
22 |
φ1.5×15 |
4-6 |
Y200L1-6 |
18.5 |
ZQ65 |
33 |
φ2×20 |
7-8 |
Y225M-6 |
30 |
ZL75 |
74 |
φ2.2×22 |
10-11.5 |
Y225M-6 |
30 |
ZL75 |
82 |
φ2.5×25 |
11-15 |
Y280S-6 |
45 |
ZL100 |
108 |
φ2.8×28 |
14-17 |
Y280M1-6 |
55 |
ZL100 |
142 |
φ3×30 |
16-20 |
YS2-355M1-6 |
112 |
ZL115 |
156 |
