Mechanical Joint Elbow for Ductile Iron pipe
- 1000 Ton / Tons per Month
- qingdao port
- T/T
You May Like
Product Details
| Material | Iron | Technics | Casting | |
| Type | Elbow | Place of Origin | Shandong, China | |
| Model Number | DN 400*90deg. | Brand Name | TD or OEM | |
| Connection | Male | Shape | Equal | |
| Head Code | Other, round |
Product Description
Specifications
Mechanical Joint ElbowDuctile Iron pipe fitting
ISO9001:2000
Electrostatic spraying of all surfaces
DN80-2000,K12
Mechanical Joint Elbow for Ductile Iron pipe
Zhucheng Three-dimensional Pipeline Com.,Ltd are mainly producing the Ductile Iorn pipe fitting, iron pipe fitting, DI pipe , flange pipe , tee fitting , elbow pipe fitting ect.
| SIZE | DN80-2000 K14,PN10/16/25 |
| Protection layer | Fusion Bonded Epoxy coating, Cement mortar lining and rich zinc & bitumen.Electrostatic spraying |
| Standard | ISO2531,BS EN545,EN598,BS4772,ANSI,AWWAC110,C153 |
| certificates | ISO9001,ISO14001,ISo18001 |
| color | green blue red black |
| Hydrostatic test: | ||
| Norminal Diameter mm | Pressure | Test time |
| ≤300 | ≥25 Pa | ≥15S |
| 350-600 | ≥16 Pa | ≥15S |
| ≥700 | ≥10 Pa | ≥10S |
| Mechanical properties: | ||||
| Name | Tensile Strength | Elongation | Yield Strength | Hardness |
| Ductile iron fittings | ≥420MPa | ≥5% | ≥300MPa | ≤250HB |
NOTE Coat of di fittings:
Interal:Portland cement mortar for Portalbe water ,Drinking water;
High-aluminium cement, Sulfur-resistant cement for Drainage ,Sewerage.
External: Rich-zinc primer plus Black Bitumen paint ;
Epoxy paint or Epoxy coat(FBE)coat,no less than 200um.
Red coating ,normally ,it is perfomed as per BS EN598 standard, suitable for Drainage, Sewerage ect. water pipeline
Payment Terms: TT30%, the balance against BL copy or workable L/C. then other payment are agreed upon request
Welcome to your inquiry!
Contact Person: Lucy Lee
Company:ZHUCHENG THREE-DIMENSIONAL PIPELINE CO.,LTD
Add: Baichihe Industrial Park, Zhucheng City, Shandong Province,China.
Tel: +86-536-6511206, +86-536-6511112
Fax: +86-536-6511206, +86-536-6511319
Mob:+86-15653682109 LUCY LEE SKYPE:lucy.lee255
