Help CenterPortable Digital Leeb Hardness Tester/ Leeb Hardness Testing Machine
Related Products
-
Hot Sales Pen Tpye Portable Hardness Tester (SHL-100)US$ 150.00 - 150.00MOQ: 1 Set -
Portable Leeb Hardness Tester, Pen Type Leeb Hardness TesterUS$ 150.00 - 150.00MOQ: 1 Set
-
SHL-180 High Accuracy Leeb Hardness Tester PortableUS$ 150.00 - 150.00MOQ: 1 Set
-
Low Price Leeb Portable Aluminum Hardness Tester With High QualityUS$ 150.00 - 150.00MOQ: 1 Set
-
Convenient Portable Leeb Hardness Tester (SHL-360)US$ 500.00 - 500.00MOQ: 1 Set
² Measuring range: (170-960)HLD,(17-68.5)HRC,(19-651)HB,
² Measuring direction: can be working at any angle (360°)
² Test material: Steel and cast steel, alloy tool steel, stainless steel, gray iron, ductile iron, cast aluminum alloy, copper-zinc alloys (brass), copper-tin alloy (bronze), copper, forged steel.
² Hardness scale: HL, HB, HRB/C, HRA, HV, HS
² Display: dot matrix LCD,128×64 dots
² Data memory: 500 groups max.(relative to impact times 32~1)
² Thermal printer, working quietly, can print any number of copies of the test results to meet test site needs.
² Printing paper: width is (57.5±0.5)mm, diameter is 30mm
² Battery pack: 6V NI-MH; Battery charging power: 9V/500mA; Charging time: 2.5-3.5 hours
² Continuous working period: about 150 hours(With backlight off, no printing)
² Communication interface: USB1.1
Steel and cast steel, alloy tool steel, stainless steel, gray iron, ductile iron, cast aluminum alloy, copper-zinc alloys (brass), copper-tin alloy (bronze), copper, forged steel.
l Based on the Leeb hardness measurement principle, can detect a variety of metal materials; with software calibration feature.
l A host can be equipped with seven different impact devices, automatically identify the type of impact device, and after replacement without recalibration.
l Supporting forged steel (Steel) material. When you use the D / DC type impact device test "Forged" sample can be directly read the HB value without having to manually look-up table.
l The hardness value can be preset lower and upper limit, automatic alarm when out of range. Convenient used for batch testing.
l Adopted large-screen 128 × 64 dot matrix LCD display, information-rich and intuitive.
l Chinese display, menu structure panel, simple and convenient operation. EL backlight display for easy use in dimly lit environments.
l Can store 500 groups (impact times 32 ~ 1) hardness measurement data, each data consists of a single measured value, the average data, testing date, impact direction, the number of materials, hardness system information.
l Thermal printer integrated with the instrument as a whole, working quietly, fast printing speed can be printed inspection report on site.
l Built-in nickel-metal hydride rechargeable batteries and charge control circuit; not less than 150 hours of continuous work; Has the power saving, automatic sleep, automatic and shutdown function.
l Remaining power of the battery can show on the LCD screen, real-time display of remaining power; With charging process indicating function, the operator can keep abreast of the charge level.
l Can quickly and easily connected with the PC for data exchange through USB interface.Can equipped with computer software, with transmission measurements, the measured value storage management, statistical analysis of measured values, print the measured value report and batch set instrument parameters etc function. So it can meet more higher requirements for quality and management.
l Compact design, portable integrated thermal printer can be printed on the spot, Dimension: 212mm × 80mm × 32mm
1. We can provide OEM service, only for dealers / agents, MOQ: 5 sets.
2. This model easy upgrade, it can add CCD camera and with software.
If need it, when make order, please let us know it.
3. Provide one year warranty, delivery within 3 days after confirmation.
4. Technical support
5. Choice the best delivery type for customers, also accept customer
pick goods from us.
