European DC Fast EV Charger Station 15kw to 150kw

Name: European DC Fast EV Charger Station 15kw to 150kw
Brand: CorePower
SKU: 103396741
Availability: InStock

US$ 350 - 30,000 MOQ: 20 Pieces

Key Specifications

Brand Name:

CorePower

Model Number:

ZK-GY04

Use:

Other, EV

Core Power (Fujian) New Energy Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FuZhou

Delivery Detail:

Delivery time depends on order quantity.

Brand Name CorePower

Model Number ZK-GY04

Use Other, EV

Type Electric

Place of Origin Fujian, China

Product Shape

Product Description

Product Description:

ZK-GY04 series of integrated intelligent DC charging piles have industry leading "a pile Shuangqiang" charging technology, through intelligent

power distribution and switching technology, intelligent and flexible deployment of the charging gun power, a charging pile up with 2 with the

charging gun, fully meet the charging station of various power electric vehicle multi car at the same time, the charging requirements. Maximize

the efficiency of charging piles, greatly improving the operating rate of the charging station.

Technical Parameters:

Modul		ZK-PW0315	ZK-PW0330	ZK-PW0360	ZK-PW0390	ZK-PW03120	ZK-PW03150
Capacity		15KW	30KW	60KW	90KW	120KW	150KW
Peak Power		18KW	36KW	72KW	108KW	144KW	180KW
Working		ZVS,PWM
INPUT
Phase		3Phase, 3Wires ,PE
Voltage		380VAC(-15%+20%)
Frequency		45Hz-65Hz
Power Factor(MAX)		≥0.99 APFC
Current THD		≤3%
OUTPUT
Voltage		0-750V DC
Current		0-20A	0-40A	0-80A	0-120A	0-160A	0-200A
Voltage Regulation		≤±0.5%FS(FS Resistor Load)
Current Regulation		≤±0.5%FS(FS Resistor Load)
Ripple		≤0.2%
Power Regulation		≤±0.1%FS
Protection grade		IP54
Efficiency		96%
Voltage and current data sampling period		<100ms
Protection		1.input / under voltage protection; 2. output over flow / short circuit protection; 3. battery anti reverse connection, overheating, lightning protection, communication interrupt, moisture-proof, anti salt spray, anti mildew, rust protection and other protective measures function
Module communication Interface		CAN 2.0
Controller communication Interface		CAN/RS485/RS232
Cooling		Fan forced cooling
Environment	operating Temperature	-20+50℃
	Temperature	10-90%RH
	Storage temperature	-30℃ +70℃
Weight(Kg)		60	80	150	220	260	300
Dimension(mm)		650mm W×1440mm H×400mm D	720mm W×1670mm H×400mm D		750mm W×1760mm H×675mm D
