KINGCHAI Power Machinery mini portable diesel engine water pump
- Specificatioin:
Model |
KC50DKB |
KC80DKB |
KC100DKB |
|
||
Water Pump |
Suction.Discharge Port did. (mm) |
50 (2 ") |
80 (3") |
100 (4") |
High Pressure Water Pump |
|
Capacity |
Max.Capacity (m3/h) |
36 |
50 |
96 |
||
ContCapacity (m3/h) |
22 |
36 |
64 |
|||
Head |
Max.Head (m) |
26 |
25 |
31 |
||
Cont.Head (m) |
15 |
13 |
16 |
|||
Self-priming Time (s/4m) |
80 |
120 |
180 |
|||
Max.Suction Head (m) |
8 |
8 |
8 |
|||
Engine Model |
KC170F/E |
KC178F/E |
KC186F/E |
|||
Rated power (Kw) |
2.5 |
3.7 |
5.7 |
|||
Bore x Stroke |
70x55 |
78x62 |
86x70 |
|||
Displacement (cc) |
211 |
296 |
406 |
|||
Compression ration |
20:1 |
19:1 |
||||
Fuel consumption (g/kw.h) |
284 |
280 |
273 |
|||
Fuel tank capacity (L) |
2.5 |
3.5 |
5.5 |
|||
Lube capacity (L) |
0.75 |
1.1 |
1.65 |
|||
Rotation direction |
Clockwise |
Clockwise |
Clockwise |
|||
Lubrication system |
Pressure splashed |
Pressure splashed |
Pressure splashed |
|||
Lube oil type |
SAE-10W30 (above DC grade) |
SAE-10W30 (above DC grade) |
SAE-10W30 (above DC grade) |
|||
Fuel type |
(summer) 0#; (winter) 10# |
(summer) 0#; (winter) 10# |
(summer) 0#; (winter) 10# |
|||
Starting system |
Recoil starter/Electric starter |
Recoil starter/Electric starter |
Recoil starter/Electric starter |
|||
Engine Speed (r/min) |
3000/3600 |
3000/3600 |
3000/3600 |
|||
N.W./G.W. (kg) |
35/37 |
52/54 |
64/67 |
|||
Dimension (LxWxH) (mm) |
500x420x500 |
560x440x550 |
650x480x600 |
|||
-Features & Picture
1.Diesel water pump,garden pump,pump,
2.Powered by air-cooled, 4-stroke diesel engine
3.Large volume water discharge
4.Highly effective mechanical seal
5.Compact and light weight structure
- Orther gaoline generator productions
-Factory & Workshop
- Packaging & Shipping
-Certificate
-Contact Information:
-FQA:
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located?
A: Our factory is in Yongkang City, Zhejiang Province, China.
we have one offce in Taizhou city, which is near Ningbo & Shanghai.
3.Q:What is the material of your products
A: Iron,Steel,plastic,etc.
only new material can be used for our products
4.Q:How about quality control in your factory?
A:"Quality is first, Customers are friends".
Yongkang Fushitong people are always paying great attentions to quality controlling from the beginning to the end. Every piece of goods is tested strictly one by one before packing.
We keep goods to meet the standard of CE,CCC, ISO9001:2000.
5.Q:How about guarantee?
A: It's within three months after goods is discharged in the destination.
During that period,if some breakdown easily spare parts need to change,my factory offers free.
For example, fuel cock,spark plug,starting hand,etc.
