Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > Aviatic Cup Injection Molding Machine
US$ 21,000 - 21,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, injection molding
Style:
Horizontal
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Aeronautic Cup Injection Molding MachineUS$ 21,000 - 21,000MOQ: 1 Set -
Good Quality Cup Injection Molding MachineUS$ 21,000 - 21,000MOQ: 1 Set
-
Washing Cup Injection Molding MachineUS$ 21,000 - 21,000MOQ: 1 Set
-
Everyday Cleaning Cup Injection Molding MachineUS$ 21,000 - 21,000MOQ: 1 Set
-
Hot-selling Plastic Cup Injection Molding MachineUS$ 21,000 - 21,000MOQ: 1 Set
Condition
New
Type
Other, injection molding
Style
Horizontal
Brand Name
Longsheng
Model Number
LSF208
Place of Origin
Jiangsu, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
347-518gr
Injection Rate
170-257g/s
Clamping Force
208T
Opening Stroke
500mm
Power(W)
15kw
Certification
ISO9001 SGS
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
injection weight:274-428grclamp force:2080KN
tie bar sizes:510*510mm
energy saving
The machine can make different size cups
We are professional manufacturer of aviatic cup injection molding machine , clamping from 600 to 32000KN, weight from 68g to 40570g can make different cups.
Machine type:
1) servo energy-saving
2)variable pump
3) high speed etc
suitable for all kinds of plastic products production.
INJECTION UNIT |
| Unit | LSF-208 | ||
A | B | C | |||
Screw Diameter | Mm | 45 | 50 | 55 | |
Screw L/D Ratio | L/D | 22.2 | 20 | 18.2 | |
Short Size | Cm3 | 381 | 471 | 569 | |
Injection weight | G | 347 | 428 | 518 | |
oz | 12.2 | 15.1 | 18.2 | ||
Injection Rate | g/s | 170 | 210 | 254 | |
Plasticizing capacity | g/s | 19 | 23.2 | 28.7 | |
Injection Pressure | Mpa | 229 | 186 | 154 | |
Screw Speed | Rpm | 0-190 | |||
Injection Sroke | mm | 240 | |||
CLAMPING UNIT | Clamp Force | KN | 2080 | ||
Space Between Tie Bars | mm | 510*510 | |||
Toggle Stroke | mm | 500 | |||
Max. Mold Height | mm | 530 | |||
Min. Mold Height | mm | 200 | |||
Ejector Stroke | mm | 150 | |||
Ejector Tonnage | KN | 62 | |||
Ejector Number | P | 5 | |||
OTHERS | Max. pump Pressure | Mpa | 16 | ||
Pump motor powder | Kw | 18.5 | |||
Heater Power | Kw | 14.25 | |||
Machine Dimension(L*W*H) | M | 5.3*1.4*1.95 | |||
Machine Weight | T | 6.9 | |||
Oil Tank Capacity | L | 380 | |||
Hopper Volume | Kg | 50 | |||
