Help CenterDry Claw Vacuum Pump (PVP-C Series)
Related Products
CONSTRUCTION:
PVP-C series dry claw vacuum pump is designed to have two balanced and contra-rotating rotors. The rotors are built with hook & claw shape to provide true positive displacement with higher pressure ratios than traditional Roots pumps.
FEATURES & BENEFITS:
Rotors of the PVP-C series dry claw vacuum pumpare machined to fine tolerance that gives maximum efficiency without the need for lubrication. This leads to extreme reliability with low maintenance cost.
Due to its simplicity, PVP-C series dry claw vacuum pumpis considerably with lower ownership cost than other types as screw or non-lubricated piston pumps.
Furthermore, the air or gas that is discharged is completely oil-free, thus there is no disposal problem at all which is associated with the sealing fluids used in liquid ring pumps or similar.
APPLICATIONS:
PVP-C series dry claw vacuum pump is used in a wide range of applications where it is desirable that gas being handled free-of-oil or other contaminants. This makes the PVP-C series dry claw vacuum pumpthe first choice in many industries such as:
- Petrochemicals (gas reclaim)
- Water treatment (biogas)
- Chemical R&D (distillation)
- Surface treatment & analysis
- Gas production and distribution
- Nuclear power generation
- Solar power generation
- Beer production & Whisky blending
- Electronics component production
SPECIFICATONS:
Model |
Speed [L/s] |
Power [kW] |
Inlet |
Outlet |
Cooling water [m3/h] |
Noise [dBA] |
Vacuum achieved [Pa] |
PVP-C-8 |
8 |
2.2 |
DN15 |
DN8 |
0.35 |
<68 |
10-1000 |
PVP-C-30 |
30 |
5.5 |
DN32 |
DN25 |
0.4 |
<68 |
10-1000 |
PVP-C-70 |
70 |
11 |
DN65 |
DN50 |
0.7 |
<75 |
10-1000 |
PVP-C-110 |
110 |
15 |
DN80 |
DN65 |
0.8 |
<75 |
10-1000 |
PVP-C-150 |
150 |
18.5 |
DN100 |
DN80 |
1.0 |
<75 |
10-1000 |
PVP-C-300 |
300 |
37 |
DN200 |
DN150 |
1.2 |
<80 |
10-1000 |
1) Data above is supposed to be as accurate as possible, but it is not bound.
2) Special model can be offered with customer’s request.
3) We reserve the right to change without notice.
