High Quality HF Series farm irrigation water pump

Specifications

High Quality HF Series farm irrigation water pump
1)A+ quality and best price.
2)Easy operation & maintenance.

High Quality HF Series farm irrigation water pump







Application and installation

The HF series pumps are specifically designed to achieve high delivery rates with low to medium heads for industrial and agricultural uses. Their volute impeller makes it able to pump water that is even fairly dirty. High delivery rates under continuous or heavy duty, making them advantageous for rain and gravity irrigation, for pumping water from lakes, river, well and for a wide variety of other applications, etc..

Pumps should be installed in a covered area, protected  against the weather.



Operating limitations

Max ambient temperature up to 40°C

Max fluid temperature up to 80°C

Max pressure up to 10 bar



Construction

Pump Body: cast iron

Motor Housing: aluminum

Shaft:45# steel /stainless steel

Impeller: Brass



Motor: closed, externally ventilated

Insulation Class: B/F

Protection Class: IP44 /IP54

Duty: continuously rated

Mechanical Seal: ceramic steatite/ metalized carbon



Technical data
