Specifications
This machine can make handbags with different specifications and is an ideal equipment of manufacturing high-standard handbag.Performance and Characteristics:
FM-350/1040 full automatic paper bag machine is the ideal equipment to take the flat papers with original colors or printed well as raw materials to make into paper bags with square bottoms. Its technique process is about: the flat papers after printing are delivered into the driving parts for positioning through automatic paper feeder and press line with rolling press device and then make one-side glue, folding and positioning and sticking and conveying device will convey them into the bottom position and conduct press horizontal line, open bottom, make glue and press together and finally output finished bag products.
Specifications:
This machine can make handbags with different specifications and is an ideal equipment of manufacturing high-standard handbag.
Main Technical Variables:
Model |
FM-35 |
Width scope of bag face |
180-350mm |
Organ height |
70-150mm |
Canister length of the paper bag |
290-600mm |
Paper width |
530-1040mm |
Paper length |
290-600mm |
Paper weight range with unit |
Brown paper(yellow brown and while brown): 80-200g |
Copperplate paper + PP peritoneum: 100-200g | |
White paperboard: 180-200g | |
Grey paperboard + PP peritoneum: 150-200g | |
Product speed |
40-70piece/min |
Glue type |
Watery glue( sticking the side can increase heat melting glue system) |
Total Power |
10kw |
Total Weight |
10T |
Overall Dimension(L×W×H) |
13000×1800×1700mm |
Remarks:
the mechanical speeds are different due to the different factors like paper quality, gram weight scope, printing result, whether stick with PP film or not, quality of sticking agent, paper size, climate and workshop environment.
Working procedure
1,paper feeding2,Automatic diecut
3,Gluing
4,Tube Formation
5,Tube
6,Bottom Folding
7,Gluing
8,Bag Output
Company Description
Ruian Fengming Machinery Co., Ltd, which has more than 15 years experience manufacture specializing in developing and producing high quality plastic machinery. Such as film blowing machine, bag making machine, printing machine, slitting machine, recycling machine, and etc. We have exported our machines to many countries. Such as USA, SPAIN, ROMANIA, MEXICO, SAUDI ARABIA, JORDAN, SYRIA, ARGENTIA, and many middle east, and south America countries. Our produce have through ISO9001 and CE certificate.
Our enterprise wil...
