Help CenterHZS-60 Stationary Concrete Mixing Plant
Related Products
-
HZS-50 Stationary Concrete/Cement Mixing PlantUS$ 70,000 - 82,000MOQ: 1 Set -
HZS-25 Stationary Concrete Mixing PlantUS$ 30,000 - 45,000MOQ: 1 Set
-
Planetary/vertical Mixer Stainless Too GoodUS$ 6,340 - 50,000MOQ: 1 Set
-
Our Concrete Mixer Can Match With Germany'sUS$ 6,000 - 50,000MOQ: 1 Set
-
Good News! Planetary Cement Mixer BlenderUS$ 6,340 - 50,000MOQ: 1 Set
1. MIXING SYSTEM
Twin Shaft Concrete Mixer: JS1000
Volume: 1600L
Capacity: 1000L
Mixing blade: 2×8 pcs
Mixing Speed: 25.5 r.min
Mixer Motor: 37kw
Weight: 9880kg
Dimensions: 4640×2250×2250mm
2. AGGREGATE SYSTEM
2.1 Aggregate batcher: PLD2400
Volume: 4×12 m3
Capacity: 144 m3/h
Power: 11kw
Weight: 7610 kg
Dimension: 10120×3320×3820mm
2.2 Aggregate Belt Conveyor 1 unit
Width: 800 mm
Speed: 1.6 m/s
Power of Motor: 11kw
3.CEMENT SYSTEM (OPTIONAL)
3.1 Cement silo 2units
Capacity: 100 t×2=200 t
Silo Diameter: Φ3000
3.2 Cement Screw Feeder 2units
Diameter: Φ219mm
Length: 9m
4. ADDITIVE SYSTEM (OPTIONAL)
Additive silo Capacity: 1m3
Pneumatic Valve: Φ50 mm
Pump: 3kw
5.WATER SYSTEM
Motor Power: 3kw
Butterfly Valve: Φ150 mm
Capacity: 80m3/h
6.AIR SYSTEM
Air Compressor 1unit
Power: 7.5 kw
Pressure: 1.0 Mpa
Air flew: 1.2 m3/min
7. WEIGHING SYSTEM
7.1 Aggregate Weighing 1unit
Weighing Capacity: 3000kg
Precision: ±1%
7.2 Cement Weighing 1unit
Weighing Capacity: 600kg
Precision: ±1%
7.3 Water Weighing 1unit
Weighing Capacity: 250 kg
Precision: ±1%
7.4 Additive Weighing: 1unit
Weighing Capacity: 40 kg
Precision: ±1%
8. CONTROL SYSTEM
PLC command and control operation .
Main electrical components : SCHNEIDER or SIMENSE
17’’ colorful computer
Manuel and Auto Control is freely changeable .
