Specifications
1.high strength stitched fiberglassnsist of two or more layers roving fiberglass
3.no-crimp fabric
biaxial cloth is a high strength stitched fiberglass +/-45°, 50" wide. This no-crimp fabric is ideal for wet layup and infusion processes which require fast wet out and strength control. This easy handling fabric can be used with polyester, vinyl ester or epoxy resin systems.
1. Products Specifications
Biaxial and Multiaxial Fabric
Style |
Mass (g/m2) |
Mass (oz/yd2) |
Roll length (m) |
Width (cm) |
Roll Weight (kg) |
Resin Compatibility |
EB450(0/90) |
450 |
13.3 |
87 |
127 |
50 |
UP or Epoxy Resin |
EB600(0/90) |
600 |
17.7 |
65 |
127 |
50 |
UP or Epoxy Resin |
EB900(0/90) |
900 |
26.6 |
35 |
127 |
50 |
UP or Epoxy Resin |
EU400(45/-45) |
400 |
11.8 |
98 |
127 |
50 |
UP or Epoxy Resin |
EU800(45/-45) |
800 |
23.6 |
49 |
127 |
50 |
UP or Epoxy Resin |
ETW750(45/-45/90) |
750 |
22.1 |
52 |
127 |
50 |
UP or Epoxy Resin |
ETW1200(45/-45/90) |
1200 |
35.4 |
33 |
127 |
50 |
UP or Epoxy Resin |
ETL800(0/45/-45) |
800 |
23.6 |
49 |
127 |
50 |
UP or Epoxy Resin |
ETL1200(0/45/-45) |
1200 |
35.4 |
33 |
127 |
50 |
UP or Epoxy Resin |
EMU900(0/45/-45/90) |
900 |
26.5 |
44 |
127 |
50 |
UP or Epoxy Resin |
EMU1200(0/45/-45/90) |
1200 |
35.4 |
33 |
127 |
50 |
UP or Epoxy Resin |
Used in: boats, wind power, basic facilities, sports apparatus, as well as the general industries.
