Specifications
Descriptions: Needled felt can be used in the automotive industry, sound absorption, shock absorption, flame retardance, etc.
1. Descriptions:
1) the Needled felt is mainly used for industrial areas; high temperature gas filtration;
2) can be used in the automotive industry, sound absorption, shock absorption, flame retardance;
3) It is widely used in gas cleaning and dust reclamation of carbon soot, steel, non-ferrous metal
and refuse burning industry.
2. Products specification
Needled Combination Mat
Style |
Mass (g/m2) |
Mass (oz/yd2) |
Roll length (m) |
Width (cm) |
Roll Weight (kg) |
Basic Fabric (g/m2) |
|
EMN360 |
360 |
10.6 |
50 |
125 |
22.5 |
150 |
UP or Epoxy Resin |
EMN400 |
400 |
11.8 |
50 |
120 |
24 |
200 |
UP or Epoxy Resin |
EMN600 |
600 |
17.7 |
34 |
120 |
24.5 |
300 |
UP or Epoxy Resin |
EMN900 |
900 |
26.5 |
25 |
100 |
22.5 |
600 |
UP or Epoxy Resin |
EMN1250 |
1250 |
36.9 |
20 |
100 |
25 |
800 |
UP or Epoxy Resin |
3. Features:
1) Three dimensional high intensity
2) Excellent ventilating performance
3) Light weight, ease of handling and cutting
4) Molding sufficiently, good cavity filling
5) Excellent surface finish, good anti-impact performance
6) Ability to withstand higher RTM pressure
7) Lower resin requirement
4. Application: this high performance needle combination mat has been designed for a wide range
of processes; including hand lay up, winding, GMT, RMT, VARMT, hot + cold press molding and
pressure bag molding. It is used as automobile top ceiling, baggage shelf, dried cloth board,
refrigeration steam carriage body, chemical anticorrosion pipeline, and high-pressure resistant
insulation product.
Flue Gas Desulfurization
