CNC 3 Roller Plate Bending Machine/ 3 Roller Plate Rolling Machine

CNC 3 Roller Plate Bending Machine/ 3 Roller Plate Rolling Machine thumbnail-1
CNC 3 Roller Plate Bending Machine/ 3 Roller Plate Rolling Machine photo-1
US$ 4,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
NFL
Model Number:
W11S
Contact Supplier Request Quote Chat Now
Maanshan New Fuli Machinery Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Anhui, China
Brand Name NFL
Model Number W11S

Specifications

CNC 3 roller plate bending machine/ 3 roller plate rolling machine
3-roller bending rolling machine
Best price in China

1. High-precision end pre-bend, the end of pre-bending freely set the length of straight edge, upper roller press down with certain pressure to implement high-precision end pre-bending.
2. Salience precision products: Persistting bending high-precision resulting in superior accuracy of products; The roller drum shape can adjust the plate from thin to thick for your ideal needing.
3. The use of different methods of the corresponding control: According to use, have the following control methods:
TNC (on NC), a small amount of multi-species production.
T & BNC (upper and lower NC), less mass-produced varieties used.
CNC (CNC), a large number of multi-species production.
4. CNC control of the production of high-efficiency: One-person simple operation, efficiency increases.
5. Rich bending shape: With rolling O-, U-type, multi-paragraph R, such as different shapes, their method:
O-bend: Rear bending way.
U-bending: Front bending way.
Special bending: Combination way.
CNC 3 roller plate bending machine/ 3 roller plate rolling machineCNC 3 roller plate bending machine/ 3 roller plate rolling machine
CNC 3 roller plate bending machine/ 3 roller plate rolling machineCNC 3 roller plate bending machine/ 3 roller plate rolling machineCNC 3 roller plate bending machine/ 3 roller plate rolling machineCNC 3 roller plate bending machine/ 3 roller plate rolling machine
CNC 3 roller plate bending machine/ 3 roller plate rolling machineCNC 3 roller plate bending machine/ 3 roller plate rolling machine
Specification Pressure on upper roller Tons Max.rolling thickness

Max.rolling width mm

 Upper roller diameter mm Lower roller diameter mm Centre distance mm  Motor kw
End mm Centre mm Drice Oil pressure Move
W11S-15*2000 75 12 15 2000 255 150 245 7.5 4 1
W11S-14*2500 75 10 14 2500 270 150 245 7.5 4 1.1
W11S-13*3000 75 9 13 3000 290 150 245 7.5 4 1.1
W11S-17*2500 100 13 17 2500 300 165 270 15 5.5 1.5
W11S-15*3000 100 11 15 3000 325 165 270 15 5.5 2
W11S-20*2500 130 16 20 2500 330 180 300 15 5.5 2.2
W11S-18*3000 130 14 18 3000 350 180 300 15 5.5 2.2
W11S-22*2500 160 18 22 2500 360 200 330 18.5 7.5 2.2
W11S-20*3000 160 16 20 3000 375 200 330 18.5 7.5 2.2
W11S-18*3500 160 14 18 3500 390 200 330 18.5 7.5 4
W11S-24*2500 190 21 24 2500 380 220 360 22 7.5 4
W11S-22*3000 190 19 22 3000 400 220 360 22 7.5 4
W11S-19*3500 190 16 19 3500 410 220 360 22 7.5 4
W11S-29*2500 230 25 29 2500 410 235 380 30 11 4
W11S-27*3000 230 22 27 3000 425 235 380 30 11 4
W11S-25*3500 230 21 25 3500 440 235 380 30 11 4
W11S-33*2500 270 28 33 2500 430 250 400 30 11 4
W11S-30*3000 270 25 30 3000 450 250 400 30 11 4



Specification Pressure on upper roller Tons Max.rolling thickness Max.rolling width mm Upper roller diameter mm Lower roller diameter mm Centre distance mm Motor kw
End mm Centre mm Drive Oil pressure Move
W11S-28*3500 270 23 28 3500 470 250 400 30 11 4
W11S-25*4000 270 20 25 4000 490 250 400 30 11 4
W11S-36*2500 320 30 36 2500 460 260 420 37 15 5.5
W11S-32*3000 320 28 32 3000 480 260 420 37 15 5.5
W11S-28*3500 320 25 28 3500 500 260 420 37 15 5.5
W11S-26*4000 320 22 26 4000 520 275 420 37 15 5.5
W11S-39*2500 380 35 39 2500 500 275 460 45 22 5.5
W11S-35*3000 380 32 35 3000 510 275 460 45 22 5.5
W11S-32*3500 380 28 32 3500 530 275 460 45 22 5.5
W11S-30*4000 380 25 30 4000 550 290 460 45 22 5.5
W11S-43*2500 430 40 43 2500 520 290 500 55 22 7.5
W11S-38*3000 430 35 38 3000 540 290 500 55 22 7.5
W11S-36*3500 430 30 36 3500 560 290 500 55 22 7.5
W11S-32*4000 430 28 32 4000 580 290 500 55 22 7.5
W11S-TNC-15*2000 Same as above
W11S-TNC-32*4000 W11ST&BNC-15*2000
W11ST&BNC-32*4000		 Same as above
