W11S-30x2500 Sheet Metal Hydraulic Rolling Machine,metal bending machine
USD $4,000 - $200,000
/ Set
1 Set(Min.Order)
- 10 Set / Sets per Month
- Shanghai
- T/T
You May Like
-
W11S-30x3000 Sheet Metal Hydraulic Rolling Machine,metal bending machine
-
W11S-40x2000 Sheet Metal Hydraulic Rolling Machine
-
W11S-50x2500 Sheet Metal Hydraulic Rolling Machine,metal bending machine
-
W11S-60x2500 Sheet Metal Hydraulic Rolling Machine,metal bending machine
-
W11S-70x3000 Sheet Metal Hydraulic Rolling Machine,metal bending machine
-
W11S-80x2500 Sheet Metal Hydraulic Rolling Machine,metal bending machine
Product Details
| Place of Origin | Anhui, China | Brand Name | NFL | |
| Model Number | W11S |
Product Description
Specifications
W11S upper roller universal plate rolling machine3-roller bending rolling machine
Best price in China with CE
1. High-precision end pre-bend, the end of pre-bending freely set the length of straight edge, upper roller press down with certain pressure to implement high-precision end pre-bending.
2. Salience precision products: Persistting bending high-precision resulting in superior accuracy of products; The roller drum shape can adjust the plate from thin to thick for your ideal needing.
3. The use of different methods of the corresponding control: According to use, have the following control methods:
TNC (on NC), a small amount of multi-species production.
T & BNC (upper and lower NC), less mass-produced varieties used.
CNC (CNC), a large number of multi-species production.
4. CNC control of the production of high-efficiency: One-person simple operation, efficiency increases.
5. Rich bending shape: With rolling O-, U-type, multi-paragraph R, such as different shapes, their method:
O-bend: Rear bending way.
U-bending: Front bending way.
Special bending: Combination way.
2. Salience precision products: Persistting bending high-precision resulting in superior accuracy of products; The roller drum shape can adjust the plate from thin to thick for your ideal needing.
3. The use of different methods of the corresponding control: According to use, have the following control methods:
TNC (on NC), a small amount of multi-species production.
T & BNC (upper and lower NC), less mass-produced varieties used.
CNC (CNC), a large number of multi-species production.
4. CNC control of the production of high-efficiency: One-person simple operation, efficiency increases.
5. Rich bending shape: With rolling O-, U-type, multi-paragraph R, such as different shapes, their method:
O-bend: Rear bending way.
U-bending: Front bending way.
Special bending: Combination way.
| Specification | Pressure on upper roller Tons | Max.rolling thickness | Max.rolling width mm | Upper roller diameter mm | Lower roller diameter mm | Centre distance mm | Motor kw | |||
| End mm | Centre mm | Drice | Oil pressure | Move | ||||||
| W11S-15*2000 | 75 | 12 | 15 | 2000 | 255 | 150 | 245 | 7.5 | 4 | 1 |
| W11S-14*2500 | 75 | 10 | 14 | 2500 | 270 | 150 | 245 | 7.5 | 4 | 1.1 |
| W11S-13*3000 | 75 | 9 | 13 | 3000 | 290 | 150 | 245 | 7.5 | 4 | 1.1 |
| W11S-17*2500 | 100 | 13 | 17 | 2500 | 300 | 165 | 270 | 15 | 5.5 | 1.5 |
| W11S-15*3000 | 100 | 11 | 15 | 3000 | 325 | 165 | 270 | 15 | 5.5 | 2 |
| W11S-20*2500 | 130 | 16 | 20 | 2500 | 330 | 180 | 300 | 15 | 5.5 | 2.2 |
| W11S-18*3000 | 130 | 14 | 18 | 3000 | 350 | 180 | 300 | 15 | 5.5 | 2.2 |
| W11S-22*2500 | 160 | 18 | 22 | 2500 | 360 | 200 | 330 | 18.5 | 7.5 | 2.2 |
| W11S-20*3000 | 160 | 16 | 20 | 3000 | 375 | 200 | 330 | 18.5 | 7.5 | 2.2 |
| W11S-18*3500 | 160 | 14 | 18 | 3500 | 390 | 200 | 330 | 18.5 | 7.5 | 4 |
| W11S-24*2500 | 190 | 21 | 24 | 2500 | 380 | 220 | 360 | 22 | 7.5 | 4 |
| W11S-22*3000 | 190 | 19 | 22 | 3000 | 400 | 220 | 360 | 22 | 7.5 | 4 |
| W11S-19*3500 | 190 | 16 | 19 | 3500 | 410 | 220 | 360 | 22 | 7.5 | 4 |
| W11S-29*2500 | 230 | 25 | 29 | 2500 | 410 | 235 | 380 | 30 | 11 | 4 |
| W11S-27*3000 | 230 | 22 | 27 | 3000 | 425 | 235 | 380 | 30 | 11 | 4 |
| W11S-25*3500 | 230 | 21 | 25 | 3500 | 440 | 235 | 380 | 30 | 11 | 4 |
| W11S-33*2500 | 270 | 28 | 33 | 2500 | 430 | 250 | 400 | 30 | 11 | 4 |
| W11S-30*3000 | 270 | 25 | 30 | 3000 | 450 | 250 | 400 | 30 | 11 | 4 |
| Specification | Pressure on upper roller Tons | Max.rolling thickness | Max.rolling width mm | Upper roller diameter mm | Lower roller diameter mm | Centre distance mm | Motor kw | |||
| End mm | Centre mm | Drive | Oil pressure | Move | ||||||
| W11S-28*3500 | 270 | 23 | 28 | 3500 | 470 | 250 | 400 | 30 | 11 | 4 |
| W11S-25*4000 | 270 | 20 | 25 | 4000 | 490 | 250 | 400 | 30 | 11 | 4 |
| W11S-36*2500 | 320 | 30 | 36 | 2500 | 460 | 260 | 420 | 37 | 15 | 5.5 |
| W11S-32*3000 | 320 | 28 | 32 | 3000 | 480 | 260 | 420 | 37 | 15 | 5.5 |
| W11S-28*3500 | 320 | 25 | 28 | 3500 | 500 | 260 | 420 | 37 | 15 | 5.5 |
| W11S-26*4000 | 320 | 22 | 26 | 4000 | 520 | 275 | 420 | 37 | 15 | 5.5 |
| W11S-39*2500 | 380 | 35 | 39 | 2500 | 500 | 275 | 460 | 45 | 22 | 5.5 |
| W11S-35*3000 | 380 | 32 | 35 | 3000 | 510 | 275 | 460 | 45 | 22 | 5.5 |
| W11S-32*3500 | 380 | 28 | 32 | 3500 | 530 | 275 | 460 | 45 | 22 | 5.5 |
| W11S-30*4000 | 380 | 25 | 30 | 4000 | 550 | 290 | 460 | 45 | 22 | 5.5 |
| W11S-43*2500 | 430 | 40 | 43 | 2500 | 520 | 290 | 500 | 55 | 22 | 7.5 |
| W11S-38*3000 | 430 | 35 | 38 | 3000 | 540 | 290 | 500 | 55 | 22 | 7.5 |
| W11S-36*3500 | 430 | 30 | 36 | 3500 | 560 | 290 | 500 | 55 | 22 | 7.5 |
| W11S-32*4000 | 430 | 28 | 32 | 4000 | 580 | 290 | 500 | 55 | 22 | 7.5 |
| W11S-TNC-15*2000 | Same as above | |||||||||
| W11S-TNC-32*4000 W11ST&BNC-15*2000 W11ST&BNC-32*4000 | Same as above | |||||||||
