W11S upper roller universal plate rolling machine

FOB Price

USD $4,000 - $200,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Anhui, China		Brand Name	NFL
Model Number	W11S

Product Description

Specifications

W11S upper roller universal plate rolling machine
3-roller bending rolling machine
Best price in China with CE

1. High-precision end pre-bend, the end of pre-bending freely set the length of straight edge, upper roller press down with certain pressure to implement high-precision end pre-bending.
2. Salience precision products: Persistting bending high-precision resulting in superior accuracy of products; The roller drum shape can adjust the plate from thin to thick for your ideal needing.
3. The use of different methods of the corresponding control: According to use, have the following control methods:
TNC (on NC), a small amount of multi-species production.
T & BNC (upper and lower NC), less mass-produced varieties used.
CNC (CNC), a large number of multi-species production.
4. CNC control of the production of high-efficiency: One-person simple operation, efficiency increases.
5. Rich bending shape: With rolling O-, U-type, multi-paragraph R, such as different shapes, their method:
O-bend: Rear bending way.
U-bending: Front bending way.
Special bending: Combination way.

Specification	Pressure on upper roller Tons	Max.rolling thickness		Max.rolling width mm	Upper roller diameter mm	Lower roller diameter mm	Centre distance mm	Motor kw
Specification	Pressure on upper roller Tons	End mm	Centre mm	Max.rolling width mm	Upper roller diameter mm	Lower roller diameter mm	Centre distance mm	Drice	Oil pressure	Move
W11S-15*2000	75	12	15	2000	255	150	245	7.5	4	1
W11S-14*2500	75	10	14	2500	270	150	245	7.5	4	1.1
W11S-13*3000	75	9	13	3000	290	150	245	7.5	4	1.1
W11S-17*2500	100	13	17	2500	300	165	270	15	5.5	1.5
W11S-15*3000	100	11	15	3000	325	165	270	15	5.5	2
W11S-20*2500	130	16	20	2500	330	180	300	15	5.5	2.2
W11S-18*3000	130	14	18	3000	350	180	300	15	5.5	2.2
W11S-22*2500	160	18	22	2500	360	200	330	18.5	7.5	2.2
W11S-20*3000	160	16	20	3000	375	200	330	18.5	7.5	2.2
W11S-18*3500	160	14	18	3500	390	200	330	18.5	7.5	4
W11S-24*2500	190	21	24	2500	380	220	360	22	7.5	4
W11S-22*3000	190	19	22	3000	400	220	360	22	7.5	4
W11S-19*3500	190	16	19	3500	410	220	360	22	7.5	4
W11S-29*2500	230	25	29	2500	410	235	380	30	11	4
W11S-27*3000	230	22	27	3000	425	235	380	30	11	4
W11S-25*3500	230	21	25	3500	440	235	380	30	11	4
W11S-33*2500	270	28	33	2500	430	250	400	30	11	4
W11S-30*3000	270	25	30	3000	450	250	400	30	11	4

Specification	Pressure on upper roller Tons	Max.rolling thickness		Max.rolling width mm	Upper roller diameter mm	Lower roller diameter mm	Centre distance mm	Motor kw
Specification	Pressure on upper roller Tons	End mm	Centre mm	Max.rolling width mm	Upper roller diameter mm	Lower roller diameter mm	Centre distance mm	Drive	Oil pressure	Move
W11S-28*3500	270	23	28	3500	470	250	400	30	11	4
W11S-25*4000	270	20	25	4000	490	250	400	30	11	4
W11S-36*2500	320	30	36	2500	460	260	420	37	15	5.5
W11S-32*3000	320	28	32	3000	480	260	420	37	15	5.5
W11S-28*3500	320	25	28	3500	500	260	420	37	15	5.5
W11S-26*4000	320	22	26	4000	520	275	420	37	15	5.5
W11S-39*2500	380	35	39	2500	500	275	460	45	22	5.5
W11S-35*3000	380	32	35	3000	510	275	460	45	22	5.5
W11S-32*3500	380	28	32	3500	530	275	460	45	22	5.5
W11S-30*4000	380	25	30	4000	550	290	460	45	22	5.5
W11S-43*2500	430	40	43	2500	520	290	500	55	22	7.5
W11S-38*3000	430	35	38	3000	540	290	500	55	22	7.5
W11S-36*3500	430	30	36	3500	560	290	500	55	22	7.5
W11S-32*4000	430	28	32	4000	580	290	500	55	22	7.5
W11S-TNC-15*2000	Same as above
W11S-TNC-324000 W11ST&BNC-152000 W11ST&BNC-32*4000	Same as above
