model Q35Y-16 type hydraulic iron worker, New Fuli more function punching and cutting machine
- 100 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- 1600 ton Heavy Duty Hydraulic Used Car Body Cutting Gantry Shear Machine OEM Accecpted
- 1600 Ton Heavy Duty Hydraulic Used Car Shell Gantry Type Shear Machine OEM Available
- 4axis 5axis Large size and thickness(0-40mm) cnc plasma cutting machine
- Automatic cnc plasma cutting machine gate cnc router 120a/200a
- Fully automatic 20mm plasma cutting machine custom size high quality
- 200mm pipe table axe for plasma metal cutting machine spare parts in weifang
Product Details
Condition: | New | Place of Origin: | Anhui, China | Brand Name: | New Fuli |
Model Number: | Q35Y | ||||
Certification: | CE | ||||
Warranty: | 1 | After-sales Service Provided: | Overseas service center available |
Product Description
Ironworker :Ten Function in One Machine, hydraulic shearing, punching, bending, notching machine
Q35Y series hydraulic ironworkers adopt hydraulic driving system. Iron worker can cut punch all kinds of holes. Various metal plates, square bar, angle steel, round iron, flat bar, profiled bars ,channel steel and joist steel can be cutted, punched and notched on the machines.
Detailed function as follow:
1) Robust and accurate steel frame
2) Large punch table with scales
3) Removable bolster for punching flanges and channel and beam
4) 2 independent hydraulic cylinders
5) 2 shielded foot controls
6) 2 Separate Die Openings for oversized punching
7) 5 working stations for wide applications
8) Power inching on all 5 work stations
9) Plate shear support/table and notching table
10) Adjustable stroke controls with indicators on both cylinders
11) Movable work light as standard
12) Overload protection on hydraulic system
13) Electric back gauge
14) 5 pieces punches and dies (punch die, angel steel, square steel, round iron and a series of shearing die)
15) Other punches and dies can be produced as clients’ requirement.
Q35Y Series hydraulic combined punching &shearing machine can cut and punch all kinds of materials such as plate, square bar, angle, round bar, channel and so on. YSD industrial hydraulic ironworkers have been designed and built to the highest quality standards in the industry. This profitable machine will serve any grueling fabrication shop for decades to come. This machine is typically in stock for quick deliveries.
1.Punching
Full range of universal punches and dies are available. Unique style allows for large angle iron punching and large channel punching. Large viewing window on stripper swing away design for ease of operation. large two piece gauging table with rulers and stop as standard fittings. Quick change coupling nut and sleeve for rapid replacement of change.
2.Shearing
Round and square bar shear has multiple holes for a variety of sizes. Adjustable hold down device for round/square bar, channel/beam cutting. Large strong guarding for max safety. The angle shear has the ability to cut angle at 45°both top and bottom leg. This gives the operator the ability to make a picture frame corner for perfect welds. Diamond shaped blade for quality cuts that is minimal material lost and deformity. Easily adjustable hold-down device for accurate plate cutting. Large 15″squaring arm with inlaid scale. Special anti-distorted blade for quality cutting. Lower blade has four usable edges. There is screw allow for gap adjust no shim needed.
3.Notching
Unique design allows for cutting of angle and flat bar. Electrical interlock safety guard and three gauging stops for precise positioning. The notching section of this hydraulic ironworker is perfect for notching out metal plate, angle iron and much more. The notching station also has an oversized table with material stops. This section of the machine can also be outfitted with the optional vee notched.
4.Bending
Also bend the plate below 500mm. All the components of Machine are of the highest quality in their safety, function, capability and maintenance.
TECHANICAL DATA AS FOLLOWS:
A Special order for the joist and channel moulds needed.
Specification Model | Unit | Q35Y-16 | Q35Y-20 | Q35Y-25 | Q35Y-30 |
Pressure | TON | 55 | 75 | 110 | 140 |
Max.cutting tickness | Mm | 16 | 20 | 25 | 30 |
Plate strength | n/mm2 | <450 | <450 | <45 | <45 |
Cutting angle | degree | 7 | 8 | 8 | 8 |
Shearing size of one stroke | mm | 16*250,8*400 | 20*330 ,10*480 | 25*300 ,16*600 | 30*355 , 20*600 |
Ram stroke | mm | 80 | 80 | 80 | 80 |
Number of strokes | cpm | 8 | 8 | 6 | 8 |
Throat thickness | mm | 300 | 355 | 400 | 600 |
Pumching thickness | mm | 16 | 20 | 25 | 26 |
Max.Puching diameter | mm | 25 | 30 | 35 | 38 |
Power of main motor | Km | 4 | 5.5 | 7.5 | 11 |
Profile for cutting | |||||
Round Bar | mm | 45 | 50 | 60 | 65 |
Square Bar | mm | 40*40 | 50*50 | 50*50 | 55*55 |
Equal Angle | 90°Shearing | 125*125*12 | 140*140*12 | 160*160*14 | 180*180*16 |
45°Shearing | 70*70*8 | 70*70*10 | 80*80*7 | 80*80*10 | |
T-Bar | 90°Shearing | 120*120*12 | 140*140*12 | 160*160*14 | 180*180*16 |
45°Shearing | 60*60*8 | 70*70*10 | 80*80*10 | 80*80*10 | |
Joist | mm | 126*74*5 | 160*86*6 | 200*102*9 | 280*124*10.5 |
Channel | mm | 126*53*5.5 | 160*60*6.5 | 200*75*9 | 280*86*11.5 |
dimensions(L*W*H) | Mm | 1640*730*1770 | 1860*800*1900 | 2355*960*2090 | 2680*1040*2330 |
Weight | Kg | 1600 | 2000 | 4800 | 6800 |
