Specifications
Are you wholesaler of Professional Audio? Need a supplier for OEM? We are a Professional Power Amplifier Supplier Contact David- Flow-through ventilation from front to back
- 150W-1300W 8ohms
- Dual fans for proper cooling to maintain proper internal operating temperature
- High power toroidal transformer
- Internal heat sinks with forced air cooling for rapid, heat dissipation
- Amplifier is noise free
- CA series provide extensive protection features such as overhead short currents, DC protection, zero current, clip limiter, soft start
CA 20 Class H Professional Power Amplifier 3 Step
CA 18 Class H Professional Power Amplifier 2 Step
CA Series
Model
CA2
CA4
CA6
CA9
CA12
CA18
CA20
Stereo Power8Ω
150W
250W
400W
520W
800W
1100W
1300W
Stereo Power4Ω
225W
275W
600W
780W
1200W
1800W
1950W
Stereo Power2Ω
270W
500W
800W
1040W
1600W
2200W
2600W
BTL 8Ω
450W
750W
1200W
1560W
2400W
3600W
3900W
BTL 4Ω
540W
1000W
1600W
2080W
3200W
4400
5200W
Frequency Response
20Hz - 20KHz +0/-0.3dB
THD+N
<0.03%@8Ω 1KHz
S/N Ratio
>90dB
>90dB
>95dB
>95dB
>93dB
>93dB
>93dB
Slew Ratio
20V/ u S
20V/ u S
30V/ u S
30V/ u S
40V/ u S
44V/ u S
44V/ u S
Damping Factor
>400
>400
>400
>400
>300
>300
>300
Crosstalk
>70dB@8Ω 1KHz
Input Impedance
20KΩ(Balance)/10KΩ(Unbalance)
Input Sensitivity
0.775V/1.0V/1.4V
Protection Features
Overheat short circuits,DC,limit and--softstart,Output
relay-Zero Current Switch,Intellctual Clip limiter
Height
2U
2U
2U
2U
3U
3U
3U
Gross Weight
21.25KG
23.75KG
25KG
27KG
42.5KG
43KG
47KG
Packing Dimensions
590×570×150MM
650×585×200MM
