Help CenterPower Amplifier CK Series(3U)
Related Products
Specifications
1 2U-3U higher selection2 150W-1100W power area
3 Use in the bar,enghtclubs,Chapel,schools
4 can endure 2ohm stereo load
CKseries have 2U-3U higher selection, and 150W-1100W power area,
CK series had some pursuits for faster of reaction speed higher of damping factor, and greater function, higher level of protect function,production technology of SMD excellent component. Amplifier of CK series also can endure 2Ω stereo load, bridge 4Ω load, suit for drive line array speaker system.
Model |
CK-800
|
CK-1100
|
Stereo Power8Ω |
800W |
1100W |
Stereo Power4Ω |
1200W |
1800W |
Stereo Power2Ω |
1600W |
2200W |
BTL 8Ω |
2400W |
3600W |
BTL 4Ω |
3200W |
4400 |
Frequency Response |
20Hz - 20KHz +0/-0.3dB |
|
THD+N |
<0.03%@8Ω 1KHz |
|
S/N Ratio |
>90dB |
|
Slew Ratio |
20V/ u S |
|
Damping Factor |
>400 |
|
Crosstalk |
>70dB@8Ω 1KHz |
|
Input Lmpedance |
20KΩ(Balance)/10KΩ(Unbalance) |
|
Input Sensitivity |
0.775V/1.0V/1.4V |
|
Protect |
Overheat short circuits,DC,limit and--softstart,Output |
|
relay-Zero Current Switch,Intellctual Clip limiter | ||
Heigh |
3U |
3U |
Cross Weight |
42.5KG |
43KG |
Dimensions |
650×585×200MM |
|
