RX Series Amplifier

RX Series Amplifier photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Changcheng LT
Model Number:
RX 2000
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Changcheng LT
Model Number RX 2000
Place of Origin Guangdong, China

Specifications

Highly efficient,highly efficient,high speed
Use current feed forward,isometric hysteresis technical 3step class H
1300W

RX series raise the power amplifier sound to new level.Exctellent component and is highly efficient,high speed,high power output circuit,current feed forward,class H and so on.High power output for better speaker performance.

Excellent component and high power toroidal transformer.

Three high circuit design(high efficiency,high speed,high current output).

Use current feed forward,isometric hysteresis technical 3 step class H.

RX series has built-in high-performance low-pass filter cut off frequency with adjustable,provide extensive protection features.

Highly efficient circuit with internal heatsinks and high flow facs that RX series can easy to face harsh environment.



Technical Specifications



 Model RX-2000 RX-3000
8Ω Stereo Power 2*1300W 2*1500W
4Ω Stereo Power 2*2000W 2*2250W
2Ω Stereo Power 2*2600W 2*3000W
8Ω BTL 3900W 4500W
4Ω BTL 5200W 6000W
 Frequency Response 5--45K±0.5dB
 THD+N <0.05%@8Ω 1/3Po
 S/N Ratio >103dB >106dB
Slew Ratio 40V/u S 50V/u S
 Damping Factor >600
 Crosstalk >65dB@8Ω 1KHz
 Input Lmpedance 20KΩ(Balance)/10KΩ(Unbalance)
Input Sensitivity 0.8V/1.6V
 Protect Overheat short circuits,DC,limit and--softstart,Output
relay-Zero Current Switch,Intellctual Clip limiter
 Heigh 3U
 Gross Weight 43KG
 Dimensions 655*590*210MM
