Specifications
OEM/ODM UHMWPE plastic parts for skating board.We provide qulity UHMWPE profild.any products can be producted.
OEM/ODM UHMWPE plastic parts for skating board
specification of uhmwpe shaped
1,High abrasion resistance;
2,100%virgin UHMWPE
3,High impact strength;
4,Lightweight & durable;
5.UHMWPE sheet custom sizes
6.Good chemical resistance
performance
Extremely high wear resistance: it is very valuable in engineering application, the ratio of carbon steel, stainless steel, bronze new wear-resisting of even higher.
High shock resistance: molecular weight reached its peak value in 2 million, more than 2 million will gradually decline.
Extremely low coefficient of friction: ultra-high molecular weight polyethylene is very wear-resisting, and low friction coefficient, good self-lubrication, is an ideal bearing bushings, slider, lining material. The use of ultra-high molecular weight polyethylene as friction parts of equipment, besides can improve the wear life, energy saving effect can be received.
Low temperature resistance: because of ultra-high molecular weight polyethylene is an excellent material toughness, and its low resistance is also very good, in - 269 °C, low temperature, still have certain ductility, and shows no sign of embrittlement.
Items |
Testing Method |
Unit |
UHMW-PE |
|
Physical Property |
Density |
D1505 |
g/cm3 |
0.94-0.98 |
Mechanical Property |
Breaking Strength |
D638 |
N/cm2 |
2900 |
Elongation at Break |
D638 |
% |
350 |
|
Notch Impact Strength |
D256 |
CJ.cm/cm2 |
Not Destroyed |
|
Hardness (Rockwell) |
D747 |
40 |
||
Thermal Property |
Melting Point |
D2117 |
°C |
136 |
Vicat Softening Point |
D1525 |
°C |
134 |
|
HDT(O.46Mpa) |
D648 |
°C |
85 |
|
Expansion Coefficient |
D696 |
10-4/°C |
1.5 |
|
Electrical Property |
Volume Resistance |
D257 |
SL-CM |
1017 |
Breakdown Voltage |
D149 |
Kv/mm |
50 |
|
Dielectric Constant |
D150 |
2.3 |
||
Others |
Water Absorption |
D570 |
% |
<0.01 |
Scaling |
Uneasy to scale |
|||
application
| Transportation machinery | Guide rail, convey belt, convey device slide block seat |
| Food processing machinery | planet wheel, bottle convey, gear ,counting bolt, filler bearing, bottle holder parts |
| Paper making machinery | water suction tank cover , bearing , skew guide wheel |
| Port machinery/ship machinery | Ship parts, suspension bridge side roller, friction block. |
| Ordinary machinery | All types of gear, bushing, liner, sliding plate, clutch, guiding unit, brake |
| Other | Cooling machine, nuclear power plant shield, electric galvanized parts, and ultra-low temperature machine parts |
UHMWPE properties
* Ultra-high molecular weight polyethylene (uhmw-pe) abrasion resistance, comparison with other materials
| material | UHMWPE | PA66 | 45# steel | brass |
| Wear rate (average) % | 0.62 | 1.51 | 4.02 | 9.8 |
* Ultra-high molecular weight polyethylene (uhmw-pe) impact performance comparison with other materials
| material | UHMWPE | PA66 | PC | ABS | PTFE | HDPE |
| Impact performance KJ/m2 | 150 | 8 | 80 | 15 | 16 | 27 |
* Ultra-high molecular weight polyethylene (uhmw-pe) has a low coefficient of friction, it can be in the absence of lubricating oil in the form of sliding or rotating work
| material | UHMWPE | PTTE | PA66 | ABS | PC | stell | glass-gold |
| the coefficient of friction | 0.05-0.11 | 0.04-0.1 | 0.37 | 0.38 | 0.36 | 0.58 | 0.5-0.7 |
why choose us
product show
Customers can make all kinds of special-shaped parts according to the drawing.
Any small size need us to cut , we can satisfy your special need .
Thank you for coming, looking forward to our cooperation.
Any question, contact me.
