PE Material uhmw PE parts for food manchines

FOB Price

USD $1 - $5 / Piece

500 Pieces(Min.Order)

Supply Ability 50 Ton / Tons per Month
Port Qingdao Tianjin
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Get lowest price Inquiry Basket

You May Like

Product Details

Place of Origin:	Henan, China	Brand Name:	Huaxiang	Model Number:	HX4--18
Plastic Modling Type:	Mould

Product Description

Specifications

PE Material uhmw PE parts for food manchines
.We provide qulity UHMWPE profiled.any products can be producted

PE Material uhmw PE parts for food manchines

specification

Material : UHMWPE

Color : white ,yellow ,black ,blue ,etc.

Dimension : any size according to your requirement

performance

Extremely high wear resistance: it is very valuable in engineering application, the ratio of carbon steel, stainless steel, bronze new wear-resisting of even higher.

High shock resistance: molecular weight reached its peak value in 2 million, more than 2 million will gradually decline.

Extremely low coefficient of friction: ultra-high molecular weight polyethylene is very wear-resisting, and low friction coefficient, good self-lubrication, is an ideal bearing bushings, slider, lining material. The use of ultra-high molecular weight polyethylene as friction parts of equipment, besides can improve the wear life, energy saving effect can be received.

Low temperature resistance: because of ultra-high molecular weight polyethylene is an excellent material toughness, and its low resistance is also very good, in - 269 °C, low temperature, still have certain ductility, and shows no sign of embrittlement.

Items		Testing Method	Unit	UHMW-PE
Physical Property	Density	D1505	g/cm³	0.94-0.98
Mechanical Property	Breaking Strength	D638	N/cm²	2900
	Elongation at Break	D638	%	350
	Notch Impact Strength	D256	CJ.cm/cm²	Not Destroyed
	Hardness (Rockwell)	D747		40
Thermal Property	Melting Point	D2117	°C	136
	Vicat Softening Point	D1525	°C	134
	HDT(O.46Mpa)	D648	°C	85
	Expansion Coefficient	D696	10-4/°C	1.5
Electrical Property	Volume Resistance	D257	SL-CM	1017
	Breakdown Voltage	D149	Kv/mm	50
	Dielectric Constant	D150		2.3
Others	Water Absorption	D570	%	<0.01
Others	Scaling			Uneasy to scale

application

Transportation machinery	Guide rail, convey belt, convey device slide block seat
Food processing machinery	planet wheel, bottle convey, gear ,counting bolt, filler bearing, bottle holder parts
Paper making machinery	water suction tank cover , bearing , skew guide wheels
Port machinery/ship machinery	Ship parts, suspension bridge side roller, friction block.
Ordinary machinery	All types of gear, bushing, liner, sliding plate, clutch, guiding unit, brake
Other	Cooling machine, nuclear power plant shield, electric galvanized parts, and ultra-low temperature machine parts

why choose us

picture show

Customers can make all kinds of special-shaped parts according to the drawing.

Thank you for coming, looking forward to ourcooperation.Any questions,contact me.
