Factory price !! 50M hydraulic water well drilling rig drill machine
Factory price !! 50M hydraulic water well drilling rig drill machine
1.XYD-130 Crawler-mounted water well drilling rig
a. the machine is equipped with crawler chassis device,easy to move with fast speed.
b. hydraulic oil pressure feed device,improve drilling defficiency.
c. pressure gauge display the condition of the bottom of the drill hole.
d. drill mast controlled by hydraulic cylinder,improve the efficiency
diesel engine adopt the electric starter,to reduce the labor itensity
2.Applications of XYD-130 crawler-mounted Water Well Drilling Rig
XYD-130 crawler-mounted drilling rig is mainly used for geological general investigation and exploration,road and tall buliding foundation exploration,kinds of hole in concrete structure,river levees,subgrade grouting hole,drilling and driect grouting,civil wellsand earth temperature central air-conditioner,etc.
Technology Parameters
Model |
HW-130 |
Drilling depth |
130m |
Maximum open hole caliber |
260mm |
End hole caliber |
75mm |
Drill rod caliber |
50mm |
Drilling angle |
90~75° |
Drilling rig weight (Exclude diesel engine) |
560kg |
Overall dimension |
2500×1000×1300mm |
Spindle | |
Spindle speed |
142, 285, 570 r/min |
Spindle stroke |
450mm |
Winch | |
Max. Lifting capacity with single rope |
960kg |
Lifting speed with single rope |
0.41, 0.82, 1.64 m/s |
Steel wire rope diameter |
13mm |
Steel wire rope cubic measure |
27m |
Mud pump | |
Type |
Horizontal single-cylinder double-acting |
Displacement (with diesel engine/electric motor) |
95/77 L/min |
Diesel engine |
s1105 18HP |
Electric motor |
Y160M-4 11kw 1440r/min |
Maximum pressure |
1.2Mpa |
Work pressure |
0.7Mpa |
Water inlet caliber |
30mm |
Water outlet caliber |
25mm |
Triangle belt |
B1575mm |
Loading time: within 5 days
Shipping : By sea
Good Cooperation
Good Quality HW80 small Water Well drill Rig/ Portable Drilling Machine
Quality Certificate
Transaction history
Contact person:Sally
Jining Hengwang Mining Machinery Co., Ltd.
E-mail: sally@
Tel/Whatsapp: +008613608916725
Trademanager:cn1501451493
Skype: 2742877292@
