Specifications
engine power(kw):43bucket capacity(m3):0.25
operating weight of total machine(kg):6310
WY75 Crawler Excavator Specification | ||
Specification |
Operating weight of total machine |
6310 kg |
|
Bucket capacity |
0.25 m³ |
|
Performance |
Swing speed |
10 r/min |
|
Traveling speed |
1.9~3.7 km/h |
|
Grade ability |
57.7% |
|
Max.digging force |
50kN |
|
Engine |
Model |
YUCHAI |
|
Rated power |
43 kw |
|
Rated speed |
2200 r/min |
|
Operation range |
Max.digging radius |
6400mm |
|
Max.digging depth |
3970mm |
|
Max.digging height |
5840mm |
|
Max.dump height |
3920mm |
Overall Dimensions |
length |
6200 mm |
|
width |
2050 mm |
|
height |
2660mm |
|
Min. Ground clearance |
346 mm |
|
Tail Slewing Radius |
1770 mm |
|
center distance of track |
1640 mm |
Hydraulic system |
Rated Pressure |
21.5Mpa |
Advantage:
1.We have more than 300 workers,plant area of more than 30000m2
2. CE and ISO certification quality assured
3.The first electrophoresis and electrostatic powder spyaying line in the field of engineering machinery in China
4.All of wearing parts come from famour supplier,Catorpillar transmission technology,Isuzu axle,high quality.
5.Each products through rigorous testing before leaving the factory.
6. The best after-sales service,use more ease
Welcome to contact me and visit my factory!
