Weighing type automatic liquid filling machine
♦Specifications
Weighing type automatic filling machine
Drum/barrel weighing liquid filling and capping
20L Drum full automatically filling and capping line
Main Functions:
Using weighing filling, high accuracy is not affected by the material. By the fast increase and slow feeding valves plus composition, both to improve filling speed but also improve filling accuracy, measurement error of less than 10 g / barrel. Filling head adopts anti-drip device, filling out materials without bubbles, good effect. Automatic control of material feed, equipped with pneumatic and pneumatic clamp lid capping device.
Type:
From the different ways of filling into submerged, splash style and hinder drawing three. From the nature of the filling material distinction explosion-proof type and general type two kinds.
The basic structure:
Semi-automatic filling machine by feeding system, weighing system, consisting of four parts closure system, rack, pneumatic control systems. Feeding system through the cylinder by a solenoid valve, respectively, to perform fast and slow feed. By the load weighing system bracket, the sensor and the weighing station components. Weighing station through the sensor directly to the rack link. Stand by capping capping system, capping the cylinder and clip gland plate cover or composition
1, Suitable Area:
It can be widely used in quantitative paints, petroleum, chemical, jam, oil, asphalt, lubrication and white glue, silicone sealant and food, medicine and other industry products weighing packaging. Special materials can be ordered.
2. The main description of structure:
Automatic filling machine is composed of empty barrels storage area, filling system, the upper cover system, gland mechanism, finished product storage area, conveying system and electric control system and so.
Filling system is composed of a feeding mechanism, a weighing mechanism, a filling mouth, a frame, a pneumatic control system composed of four parts. The feeding mechanism is composed of an electromagnetic valve respectively through the cylinder performs fast and slow feeding; weighing mechanism is composed of a weighing sensor and the weighing platform support, the composition; the weighing platform are connected through a sensor and cylinder. Filling nozzle height can be loosened by the elastic clamping block on the inner six angle bolt to the required position tighten the inner six angle bolt to adjust.
The upper cover system is composed of deposit cover frame, cover cylinder and the clamping suction cover for cylinder cover, etc.
3.Specification
No |
specification |
Voltage |
380 V 50 Hz (three phase ) |
Power |
0.75 Kw |
Conveyer Speed |
0~10 M/Min |
Air pressure |
0.6 Mpa |
Fill speed |
160~200/H |
Filling quantity |
5~20 Kg |
Tolerance |
±0.5% |
♦ Company profile
♦ Frequently Asked Questions
Q: Can I visit your factory?
A: Yes. Many domestic and international customers visit our factory every year.
Q: How long is the warranty of your equipment? Do you supply spare parts?
A: Our warranty period is one year generally. We can supply spare parts.
Q: Do you provide after-sale service?
A: Yes. We have a professional after-sale service team to promptly and thoroughly solve your problems.
Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passports.
Q: Do you provide beneficiation flow chart?
A: Yes, our experienced engineers are specialized in dedign various mixer and filling line and all is based on your requirements.
Q: Can we take material and do a test in your factory? A: Before you coming, just contact with me if we has the machine in factory yes you can test. ?
A: Yes. You can send your samples to us for test and analysis.
Q: For the function mixer , the viscosity of material is 50000cps,does mixing it is ok?
A: yes that is no problem ,we has double planetary mixer and tri-shaft mixer,which both main for the high viscosity.
Q: our material is Mayonnaise, does your vacuum emulsifying mixer mixing it is ok?
A: That depend on your technology art, some clinets just using vacuum emulsifying mixer is ok but some need connect with our colloid mill. colloid can mill the material more fine and smooth.
