Help CenterNW31C Telecom Equipment of ZTE Supplier
Related Products
-
NW31C Telecom Shelter Power Environment Supervision SystemUS$ 1 - 300MOQ: 1 Set -
NW31C Telecom Site Remote Monitoring Controller ZTE SupplierUS$ 1 - 300MOQ: 1 Set
-
NW31C Telecommunication Base Station Remote Monitoring SystemUS$ 1 - 300MOQ: 1 Set
-
HW14 Telecommunications Remote MonitoringUS$ 1 - 500MOQ: 1 Set
-
DS04 Remote Monitoring Controller for 3g Base StationDS04 Remote Monitoring Controller for 3g Base StationUS$ 200 - 500MOQ: 1 Set
Specifications
A good but economic solution for telecom site remote monitoringSite environment & security monitor
DC fan controlling
NW31C telecom site remote monitoring system controls the work of DC fans based on indoor and outdoor temperature, indoor humidity.
Control logic is smart, simple and stable, it can help energy saving.
Output a start signal for ventilation system, through relay (free dry contact).
Monitor door/ fire/ flood/ high temp./ battery voltage/ DC fan failure.
Output alarm signal via relay when has fan failure or environmental abnormal.
Feature:
1. DC power supply (DC48V).
2. parameter is programmable
3. monitor indoor/outdoor temperature, indoor humidity.
4. monitor fire/door/flood/high temp./ fan failure
5. alarm output via relay (dry contact)
6. control the work of DC ventilation system
7. real time logging alarm/ environmental condition
| Function: | |
| Display | 2 groups of LED display temperature, humidity and alarm codes |
| Temperature detect range | 2 channels, detect range: -30°C ~ 70°C |
| Humidity range | 1 channels, detect range: 5% ~ 95% |
| Control | control the work of DC fan based on indoor and outdoor temperature, indoor humidity, maximum 2 groups |
| Monitor | high temp. / fire/ door open/ flood/ low voltage/DC fan failure/ temp. sensor failure/ humidity sensor failure/ high humidity |
| Alarm | 6 relays to output alarm signal |
| logging | real time logging alarm/ environmental condition |
| Communication | supply monitor software (installed in PC), RS485 |
| Technical parameter: | |
| Rating voltage | DC +42V~DC +57V |
| Work ambient temperature | -25°C~+55°C |
| Work ambient humidity | 5%~95%RH |
| Temperature detect range | -30°C~+70°C, compensation can be reset via button |
| Temperature accuracy | ±2°C |
| Temperature resolution | 1°C |
| DC fan on temperature | 10°C~50°C, programmable |
| DC fan off temperature | 10°C~30°C, programmable |
| Sample interval | 0~99 min |
| Maximum recordings | 4000 pcs |
| Communication address | 1 ~ 99 |
| DC fan control logic: | |
| On | 1)indoor temperature > preset of ‘on temperature’ 2)indoor temperature – outdoor temperature > 5°C (programmable) |
| Off | 1)Indoor temperature < preset of ‘off temperature’ 2)indoor temperature ≤ outdoor temperature 3)indoor humidity > preset of ‘high humidity’ |
| When outdoor temperature sensor has fault, controller control the work of DC fan based on indoor temperature. When indoor temperature sensor has fault, controller on the DC fan always work. | |
About our company
Hangzhou Xinjian Electronic Co., Ltd. is an ISO9001 certified hi-tech manufacturer, which has been specialized in designing and producing industrial control solution since 1997. All of our products are designed and made for the global market. We’ve offered OEM/ODM service to world-class brands and have been highly recognized not only for the good quality but also excellent after-sales services both in domestic and international market.
