Home > Products > Vacuum emulsifying mixer > 304 stainless steel jacketed high intensity mixer/disperser/homogenizer/emulsifier
304 stainless steel jacketed high intensity mixer/disperser/homogenizer/emulsifier
USD $13,000 - $17,000
/ Piece
1 Piece(Min.Order)
- 20 Piece / Pieces per Month
- shanghai
- T/T
You May Like
Product Details
| Condition: | New | Mixer Type: | Homogenizer | Product Type: | Cosmetic |
| Application: | Liquid with Suspended Solids | Additional Capabilities: | Coating | Place of Origin: | Jiangsu, China |
| Brand Name: | ZT | Model Number: | ZT-200 | Max. Loading Capacity: | 3000L |
| Voltage: | 220V/380V | Power(W): | 4kw | Dimension(L*W*H): | 1750*650*2150~2850mm / |
| Certification: | ISO9001 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Product Description
304 stainless steel jacketed high intensity mixer/disperser/homogenizer/emulsifier
♦Specifications
ZT-100/200 Vacuum Emulsifying Mixer
ZT-100/150/200 Vacuum Emulsifying Mixer
Technial parameters:
Emulsifyingpot | Design Volume(L) | 130/150/200 |
Capacity(L) | 100/120/160 | |
Scraper Stirring Power(kw) | 1.5/1.5/2.2 | |
Scraper Stirring Speed(rpm) | 0-65 | |
Homogenizer power(kw) | 3/4/4 | |
Electrical heating power(kw) | 6/6/8 | |
Homogenizer speed (rpm) | 2800 | |
Vacuum pump powder kw | 0.55/1.5/1.5 | |
Lifting motor powder kw | 0.75/1.5/1.5 | |
Water pot
| Design Volume(L) | 100/100/120 |
Capacity(L) | 80/80/95 | |
Stirring power(kw) | 0.55/0.55/0.75 | |
Stirring speed(rpm) | 1400/1400/1400 | |
Electrical heating power(kw) | 4/6/8 | |
Oil pot | Design Volume (L) | 50/75/100 |
Capacity (L) | 40/60/80 | |
Stirring power (kw) | 0.55/0.55/0.75 | |
Stirring speed (rpm) | 1400/1400/1400 | |
Electrical heating power (kw) | 4/6/8 | |
size | Mian pot | 1750*650*2150~2850mm / 1900*780*2380~ 3000mm/ 1450*600*2650~3500 mm |
Auxiliary | 1220*610*1300 mm / 1170*710*1500 mm/ |
Factory view:
