Specifications
Monitor environment condition, output alarm signal, record alarm information, front connect ports.
BTS intelligent environmental monitoring system DS04 is our new product, designed for microwave site. Use 1U standard case, easy installation. It can monitor temperature / humidity / fire / intrusion/ DC battery/ immersion. Can record maximum of 4000 pcs of recording with real time clock, and read by USB interface.
We are much experienced in research surveillance system for unmanned mobile shelter.
Function: | |
Set |
Supply 3 buttons to set |
Display |
4 bits of LED to display |
Monitor |
Monitor 2 channels of temperature, 1 channel of humidity, 2 channels of intrusion, 1 channel of immersion, 1 channel of smog fire |
Alarm signal input |
Output 6 alarm signal, includes high temperature, intrusion 1, intrusion 2, smog fire, immersion, other alarm |
Alarm output |
Use 6 pcs of relay to output alarm signal, it also display alarm code. |
Communication |
Supply USB communication function, also supply monitor software for free |
Record |
Can real time record 4000 pcs of recording |
Size of box |
Standard 1U case, for 19’’ frame |
Other |
Sample interval can be set |
Performance Indices: | |
Type |
XJK-DS04 |
Rating voltage |
AC 220V 50Hz or DC 48V |
Connect terminal position |
Front |
Interval range |
0-99min |
Temperature precision |
±1°C |
Humidity precision |
±5% |
Output |
Dry contact (N.O.) |
Communication interface |
USB |
Record capability |
4000 pcs |
Clock error |
3 seconds per month |
Sensor: | |||
Type |
Name |
Number |
Note |
WD |
Temperature sensor |
1 |
Accessories, fixed outside |
WS3 |
Hygrothermograph sensor |
1 |
Accessories, fixed inside |
SS-168P |
Smog sensor |
1 |
Accessories, fixed inside |
HO-03 |
Intrusion sensor |
2 |
Accessories, fixed on the door |
TT |
Immersion sensor probe |
1 |
Accessories, put it on the floor |
Alarm code: | |
Code |
Definition |
E01 |
High Temp. alarm |
E02 |
Intrusion 1 (door open) alarm |
E03 |
Intrusion 2 (door open) alarm |
E04 |
Smog fire alarm |
E05 |
Power off |
E06 |
Seeper |
E12 |
Temperature sensor fault |
E17 |
High humidity alarm |
