Specifications
BTS environment monitoring system monitors environmental conditions, such as temperature,humidity, smoke and intrusion.BTS environment monitoring system is our main product, design for unmanned mobile shelter/GSM shelter/BTS shelter. It can control the work of temperature equipments (e.g. heater, A/C, DC fans) based on indoor/outdoor temperature and humidity to supply a suitable condition for electronical equipment. Monitor fire, intrusion, immersion, power, voltage of battery, lightning, work state of temperature equipment. It also supply AC distribution function. It has patent, code is ZL 2008 2 0178272.0.
AC distribution box (DB), environment surveillance controller (ESC), DB25 connect wire and sensors compose an environment surveillance system.
Function: | |
Set |
Supply 4 buttons to set |
Display |
2 group of LED to display |
Monitor |
Monitor power (includes AC and battery) and environment station |
Alarm output |
Use 6 pcs relays to output alarm signal, it also supply 17 alarm codes. |
Protect |
Supply C class lightning protection Supply short circuit and overload protection If temperature sensor has fault, start a A/C |
Communication |
Supply RS232/RS485 communication function, also supply monitor software for free |
Record |
Can real time record 3000 pcs alarm or work state messages |
Energy saving |
Perfect intelligent temperature control logic can save energy |
AC distribute |
DB supply AC distribute function |
Size of DB |
500*700*180 |
Size of ESC |
390*250*80 |
Sensor: | |||
Type |
Name |
Number |
Note |
WD3 |
Temperature sensor |
1 |
Accessories, fixed outside |
WS2 |
Hygrothermograph sensor |
1 |
Accessories, fixed inside |
SS-168P |
Smog sensor |
1 |
Accessories, fixed inside |
HO-03 |
Intrusion sensor |
1 |
Accessories, fixed on the door |
TT |
Immersion sensor probe |
1 |
Accessories, put it on the floor |
DD5 |
Power off sensor |
1 |
Fixed in the DB |
IA5 |
Current sensor |
1-3 |
Fixed in the DB |
|
Moving sensor |
1 |
Optional |
Alarm code: | |||
Code |
Definition |
Code |
Definition |
E01 |
High Temp. alarm |
E11 |
Arrester module fault |
E02 |
Intrusion (door open) alarm |
E12 |
Temperature sensor fault |
E03 |
Smog fire alarm |
E13 |
Heater fault |
E04 |
Smog sensor fault alarm |
E14 |
Low voltage of battery |
E05 |
Power off |
E15 |
Spare 1 |
E06 |
Seeper |
E16 |
Spare 2 |
E07 |
A/C I fault |
E17 |
Spare 3 |
E08 |
A/C II fault |
E18 |
Warning code of A/C I |
E09 |
DC fans fault |
E19 |
Warning code of A/C II |
E10 |
Moving alarm |
|
|
