Specifications
Monitor cell site environmentOutput alarm signal
Record alarm information
-
Product Description
- It’s our new product, designed for small cell site.
- 1U standard case, easy installation.
- Monitor temperature / humidity / fire / intrusion/ power off/ water leakage.
Function: | |
Set |
Supply 4 buttons to set |
Display |
2 group of LED to display |
Monitor |
Monitor 3 rooms maximum, includes power (includes AC and battery), temperature, humidity, intrusion, immersion, smog fire |
Alarm signal input |
3 channels of nameable port, can set as DC fans fault signal or air-conditioner fault signal, and 1 channel of spare alarm signal input port |
Alarm output |
Use 6 pcs relays to output alarm signal, it also supply 13 alarm codes with room code. |
Communication |
Supply RS232/RS485 communication function, also supply monitor software for free |
Record |
Can real time record 2000 pcs alarm or work state messages |
Size of box |
Standard 1U case, for 19’’ frame |
Sensor: | |||
Type |
Name |
Number |
Note |
WD |
Temperature sensor |
1 |
Accessories, fixed outside |
WS3 |
Hygrothermograph sensor |
1-3 |
Accessories, fixed inside |
SS-168P |
Smog sensor |
1-3 |
Accessories, fixed inside |
HO-03 |
Intrusion sensor |
1-3 |
Accessories, fixed on the door |
TT |
Immersion sensor probe |
1 |
Accessories, put it on the floor |
Alarm code: | |
Code |
Definition |
Room code--E01 |
High Temp. alarm |
Room code--E02 |
Intrusion (door open) alarm |
Room code--E03 |
Smog fire alarm |
E05 |
Power off |
E06 |
Seeper |
E07 |
A/C I fault |
E08 |
A/C II fault |
E09 |
DC fans fault |
E10 |
Moving alarm |
Room code--E12 |
Temperature sensor fault |
Room code--E17 |
High humidity |
E20 |
Spare alarm |
Where it is used
About our company
Hangzhou Xinjian Electronic Co., Ltd. is an ISO9001 certified hi-tech manufacturer, which has been specialized in designing and producing industrial control solution since 1997. All of our products are designed and made for the global market. We’ve offered OEM/ODM service to world-class brands and have been highly recognized not only for the good quality but also excellent after-sales services both in domestic and international market.
