Vaisala DMT143 Dew Point Sensor

Specifications

Dew point meter contains a dew pint display, a VAISALA DRYCAP DMT143 dew point sensor/transmitter.

Feature of Model DMT143 dew point sensor/ transmitter
tection of probe: IP65
2.output signal: 4-20mA
asurement range: -80 ~ 20°C
4.maximum pressure: 50bara/725psi
ambient: -5~55°C/ 0~ 99%RH
6.accuracy: ±3°C
7.material of probe is 316L stainless steel
8.interface of probe is G1/2'' (outer screw thread)
9.max. cable length: 5m

Function of Model XJZ-3S5 dew point display
1.display dew point value
2.output alarm signal via relay (N.O dry contact) when dew point is abnormal
3.detect range is programmable
4.RS485 communication

Technical parameter of Model XJZ-3S5 dew point display
1.rating voltage: AC 220V
2.dew point range: -80 ~ 20C
3.display: 3 pcs of 0.8’’ LED
4.installation method: panel-mounted
5.install hole size: 92x92mm
6.box size: 96x96x90mm

Parameter list table
