Place of Origin China
Engine Type Diesel
Type Piston

4025102 Piston Kit with Factory Direct Price


1.Description of Piston Kit 4025102

Item Name           Piston Kit
Brand
Kit No. 4025102, Including

Piston, Engine  3921888                                           Retaining  3920691

Ring set 3802421

Pin 3934047

More information as below:

1.One engine piston kit includes 1 pc piston,2 pcs retaining ring,1 sets piston ring!

2.Made by OE manufactory!

3.Got IS014001 OHSAS8001 TS16949 certificates!

4.Form a complete set for many diesel engine works at home and abroad,batch exporting piston to overseas market!



2. Motor Piston Kit 4025102 Assembly Drawing and Specifications

4025102 3920691 Piston Kit

3.Process Flow Diagram

4025102 3920691 Piston Kit

4:We have two types package for piston kit,as Packing 1 and Packing 2.  According to your demand,we can pack the goods as you hope.

Packing 1

4025102 3920691 Piston Kit

Explain package :

engine piston kit brand package,with remarks outside.

6pcs/ carton as attached.

at the bottom of the all cartons packed by pallets.fumigation-free Plywood pallets.

Packing 2

4025102 3920691 Piston Kit4025102 3920691 Piston Kit

Explain package :

This is neutral package.

It's easy to pass the custom.

6pcs/ box as attached.

at the end of the all wooden boxes packed by pallets.fumigation-free Plywood pallets.

5:Our company also can supply other models piston kit as below:



NO. Item Description Piston Kit NO. Piston NO. Engine Model
1 piston kit 3806270 3926990 B series
2 piston kit 4955365 4938619 B series
3 piston kit 4990586 4991277 4BT/6BT
4 piston kit 3802160 3907163 6BT
5 piston kit 3802132 3908815 6B
6 piston kit 3802134 3908816 6B
7 piston kit 3802757 3930187 4BT/6BT
8 piston kit 3802251 3917619 4B/6B
9 piston kit 3802252 3919047 4B/6B
10 piston kit 3802253 3919048 4B/6B
11 piston kit 3802561 3926631 6BT
12 piston kit 3802562 3926632 6BT
13 piston kit 3802563 3926633 6BT
14 piston kit 3802564 3926634 6BT
15 piston kit 3802565 3926635 6BT
16 piston kit 3802100 3907156 6BTA
17 piston kit 3802102 3907157 6BTA
18 piston kit 3802104 3907158 6BTA
19 piston kit 3802630 3922687 6BTAA
24 piston kit 4089842 C6204382190 B3.3
25 piston kit 4025237 C6205312172 B3.3
26 piston kit 4025202 C6205392172 B3.3
27 piston kit 4025205 C6205382172  B3.3
28 piston kit 3800879 6204312141 B3.3
31 piston kit 4089967 6204312170 QSB3.3/B3.3
32 piston kit 4955548 6204392170 QSB3.3/B3.3
33 piston kit 4955550 6204382170 QSB3.3/B3.3
34 piston kit 4089968 6205312190 B3.3
35 piston kit 4956109 4995845 6C
37 piston kit 3802601 3925878 C
38 piston kit 3802602 3925879 6C 260hp
39 piston kit 3802603 3925880 6C 260hp
40 piston kit 3802604 3925881 6C 260hp
41 piston kit 3802263 3917707 6C 300hp
42 piston kit 3802279 3919564 6C 210PS
43 piston kit 3802379 3923163 6C 210PS
44 piston kit 3802396 3923165 6C 300PS
45 piston kit 3802460 3926961 6C
46 piston kit 3802461 3926962 6C
47 piston kit 3802462 3926963 6C
48 piston kit 3802568 3926964 6C
49 piston kit 3802657 3929161 6CT
50 piston kit 3802398 3923164 6C
51 piston kit 3802280 3919566 6CTA
52 piston kit 3802281 3919565 6CTA 240hp
53 piston kit 3802474 3923537 6C 230hp
54 piston kit 4025011 3972884 ISBe
55 piston kit 4025011 4897512 ISBe QSB5.9
56 piston kit 4089420 3972885 ISBe
57 piston kit 4089421 3972886 ISBe
58 piston kit 4955190 4933120 ISC
60 piston kit 3800318 3942106 ISCe/6C/QSC
61 piston kit 3800320 3943367 ISCe
62 piston kit 4955337 4935932 ISDe/ISBe/QSB
63 piston kit 2881748 5258754 ISF3.8
64 piston kit 4089944 3950395/4941395/3                                ISLe
65 piston kit 4309218 4913795 K19
66 piston kit 3803313 3070705 K19
67 piston kit 3631246 3096680 K19
68 piston kit 4089976 3966675 K19/K38/K50
69 piston kit 4089977 3966676 K19/K38/K50
70 piston kit 3803530 3628731 K19/K38/K50
71 piston kit 3631241 3096685 K19/K38/K50
72 piston kit 3631242 3096683 K19/K38/K50
73 piston kit 3631244 3096682 K19/K38/K50
74 piston kit 3631245 3096681 K19/K38/K50
75 piston kit 3631246 3096680 K19/K38/K50
76 piston kit 3804747 3630913 K38/K50
77 piston kit 3631245 3096681 K50
78 piston kit 3803976 3896031 M11
79 piston kit 4025161 3103752 M11
80 piston kit 4089865 4059900 M11
81 piston kit 4024941 4022533 4022532 M11
82 piston kit 4024938 4059949 4059948 M11/QSM
84 piston kit 3801819 3048808 NT855
86 piston kit 4955160 3975868 4931888 4934860 QSB
87 piston kit 3802925 3948468 QSB
88 piston kit 3802926 3948469 QSB
89 piston kit 3802927 3948465 QSB
90 piston kit 3802928 3948466 QSB
91 piston kit 3802929 3948467 QSB
92 piston kit 3800781 3946153 QSB5.9
93 piston kit 3800782 3946154 QSB5.9
94 piston kit 3800783 3946155 QSB5.9
95 piston kit 3800784 3946156 QSB5.9
96 piston kit 3800785 3800785 QSB5.9
97 piston kit 4955481 4934816 QSB6.7
98 piston kit 3957797 3957795 S6D102
99 piston kit 3802747 3928673 S6D102
100 piston kit 3804746 3081725 K19/K38/K50
101 piston kit 3804885 3630916 KTA50G3G8G9
102 piston kit 3019287 3037413 V903
103 piston kit 3804572               4955236 3090071/4922319  K19
104 piston kit 3803962 3803556 3893751 L10
105 piston kit 3803965 3044448 L10
109 piston kit 3803741 3087634 N14
110 piston kit 3803754     3803364 3064259 3081268 N14
111 piston kit 3801703 3048650 NT855
