Home > Products > Belt Conveyors & Sand Washing > High Screening Efficiency sand washing machine 2XL-915, spiral classifier sand washing machine
High Screening Efficiency sand washing machine 2XL-915, spiral classifier sand washing machine
USD $1,000 - $10,000
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- SHANGHAI
- T/T
You May Like
-
High Screening Efficiency sand washing machine XL-1115, spiral classifier sand washing machine
-
Hot Selling small sand washer/sand washer/sand crushing line
-
2014 Hot Selling sand washing plant/sand washer/sand crushing line
-
Screw sand washing machine/sand washer/sand crushing machine
-
High effective sand washer machine/sand washer/sand crushing machine
-
China leading Sand Washing Machine manufacturer TRUSTON/sand washer/sand crushing machine
Product Details
| Condition | New | Motor Type | AC Motor | |
| Power(W) | 11*2-15*2(KW) | Capacity(t/h) | 200 | |
| Place of Origin | Shanghai, China | Brand Name | TRUSTON | |
| Model Number | spiral classifier sand washing machine | Dimension(L*W*H) | see the specifications | |
| Weight | see the specifications, 11.5t | Certification | ISO. CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
sand washing machine 2XL-9151.single spiral classifier
2.double helixes spiral classifier
3.spiral classifier sand washer
High Screening Efficiency sand washing machine 2XL-915 for Mining, spiral classifier sand washing
1. Spiral Classifier Sand WasherSpecifications
| Model | Screw Diameter(mm) | Selected Size(mm) | Capacity(t/h) | Power(kw) | Weight(kg) |
| XL-915 | 915 | <10 | 100 | 11 | 6585 |
| 2XL-915 | 915 | <10 | 200 | 11×2 | 11555 |
| XL-1115 | 1115 | <10 | 175 | 18.5 | 10710 |
| 2XL-1115 | 1115 | <10 | 350 | 18.5×2 | 16700 |
| XL-1370 | 1370 | <10 | 250 | 30 | 14530 |
| 2XL-1370 | 1370 | <10 | 490 | 30×2 | 25610 |
| XL-1676 | 1676 | <10 | 360 | 45 | 18570 |
| 2XL-1676 | 1676 | <10 | 725 | 45×2 | 41930 |
| 2XL-1830 | 1830 | <10 | 860 | 55×2 | 18570 |
| XL-928 | 928 | <65 | 155 | 22 | 6200 |
| 2XL-928 | 928 | <65 | 315 | 22×2 | 10990 |
| XL-1118 | 1118 | <75 | 225 | 30 | 9300 |
| 2XL-1118 | 1118 | <75 | 450 | 30×2 | 16350 |
| XL-905 | 905 | <75 | 125 | 110 | 22800 |
| XL-1120 | 1118 | <100 | 175 | 160 | 31950 |
2. Sand Washer Introduction
Sand washer is suitable for washing, classifying and dewatering of sand used in construction, quarry, hydropower station, concrete dam project, pole factory, as well as "soul-rending nature sand" for casting use,quartz sand for glassworks, and pressure sand for oil well backfill. With inclination angle of 180 , a setting pond is formed and surrounede by three-side plates at the bottom of water channel.The spiral head submerges into the setting pond,the spiral rotates continuously driven by motor and reducer, and clean water is fed into setting pond through the bottom perforated plate.
| |
| |
| |
