Specifications
Meeting geothermal heat pump1.12-years heat pump manufacturing experiences
2.Famous brand components
3.CE RoHS approved
geothermal system,geothermal heating systems,furnace
Meeting geothermal heat pump low cost heating systems better than furnace 15, 19kw
- Meeting geothermal heating system heat pump
Meeting geothermal heating system heat pump adopt high efficiency famous compressor with strict quality standard, performs good heat capacity.
Meeting geothermal heating system heat pump MDS40D, MDS50D parameters
| MODEL | Unit | MDS40D | MDS50D | |||
| Rated heating capacity | KW | 15 | 19 | |||
| Hot water supply | L/h | 350 | 400 | |||
| Average heating input power | KW | 3.6 | 4.4 | |||
| Rated heating input current | A | 15A/8A | 9 | |||
| Max outlet water temp | °C | 60 | 60 | |||
| Cooling capacity | KW | 9 | 14 | |||
| Power | V/Hz | 380V/50 | 380V/50 | |||
| Noise | Db(a) | 50 | 50 | |||
| Dimension | W*D*H | mm | 657×557×780 | 657×557×780 | ||
| Packing size | W*D*H | mm | 730×630×920 | 730×630×920 | ||
| Unit weight | KG | 160 | 160 | |||
| Refrigerant | R417A/R407C | R417A/R407C | ||||
| Working air temp range | °C | (-40°C)—45°C | (-40°C)—45°C | |||
| compressor | Type | Copeland | Copeland | |||
| water source heat exchanger | Type | Plate heat exchange | Plate heat exchange | |||
| Pipe size | DN | 32 | 32 | |||
| Hot water side heat exchange | Type | Coil heat exchanger | Coil heat exchanger | |||
| Water flow | L/H | 4000L/h | 6000L/h | |||
| Water pressure down | Kpa | 40 | 40 | |||
| Pipe size | DN | 25 | 25 | |||
Simple installation diagram for Meeting geothermal heating system heat pump
Meeting ground source heat pump product features:
--high efficiency heat pump
- Compressor: world famous brand compressor—Copeland scroll with strong compression efficiency,make a 4 and above COP
- Double pipe heat exchanger (hot water side): American internal and external thread pipe technology, exceed the touching area of high pressure ,high temperature gas with water, makes a better a heat transfer
- Plate heat exchanger (water source side): special design -- one line water. One line high temperature gas, high efficiency heat transfer, especially for good quality water
--easy operation and stable working heat pump
- Electronic expansion valve: Japanese new technology with our company own design control system, automatically flow according to different temperature factors, makes the heat pump working stably
- Intelligent control system with LCD Touch screen: time on/off clock, anti-defrosting function, simple water compensation / water supply operating function, makes the most easy using heat pumps
Optional:
- R407c, R417a refrigerant is available according to customers’ requirements.
- Stainless steel cabinet is available
Meeting geothermal heating system heat pump spare parts
Commercial terms
1> Packing: Standard Export Packing (Ply wooden case)
2> Payment term: 30% T/T Of Total value as deposit to start the produce, And 70% the balance before shipping
3> Delivery time: within 15 to 20 days after receive the deposit
4> MOQ=5pcs.
1. OEM service
2. Customized service: change cabinet (stainless steel cabinet), water to air heat pump production for special needs, add BMS control function (one computer could control many heat pumps)
Certificates for Meeting geothermal heating system heat pump
Hot sale Meeting heat pumps
1. Which price terms do your company could accept?
It depends on your choice. FOB, CIF, DDU, CAF, etc
2. What is the payment we could accpet?
Generally, T/T is the most frequently we used payment.
3. Can I choose my own forwarder?
Yes, of course you can. And we will charge some fee. Like Documents fee, Clear custom fee, ENS fee.
4. If I do not know how to choose a suitalbe heat pumps, what can I do?
Please kindly inform me the area of place, air temperature, and water flow etc information, I would like choose the most suitable heat pump to you.
5. What if I want buy some spare parts from your company?
Welcome, generally, the spare parts could delivery to your door in 5 to 7 days. However, Freight would be expensive. So, you could buy it with heat pumps.
6. Any discount If I place a large order?
Yes, we could talk details.
7. What if there are some problems of the machine?
Any problem, please kindly inform me. I am ready to answer in any time.
---------------------------------------------------------------------------------------------------------------------------------------------------------------
