Wheat Straw Paper Making Machine

Machine Model

1092

1575

1760

2200

2500

2800

Width (mm)

1350

1750

1900

2150

2450

2750

Finished Products Diameter

Φ 60~150mm (Tightness can be adjustable)

Finished Products Inner Diameter

Φ32~50 mm

Jumbo roll diameter (mm)

Φ 1200 (Other sizes can be ordered)

Jumbo Roll Inner Diameter

3”,76.2 mm (other sizes can be ordered)

Perforation distance (mm)

4 blade,90~160mm;2 blade,180~320mm;

Production speed

160-180 m/min

Parameter set

Touching-screener Multi-menu Man-machine Interface Operation System

Programmable controller

Mitsubishi PLC program

Mechanical driving

Driven by stepless speed-regulator to guarantee the precise length of final products.

Embossment unit

Single embossment, Double embossment, Steel to steel embossment;

Embossment down roller

Felt roller, paper roller, rubber roller

Jumbo roll stand

1-3 plies (ply quantity can be ordered)

Air pneumatic system

3 Pa (air-compressor), the minimum pressure 5kg/cm2 pa (customers should be prepared by themselves)

Power

5.5-15KW  (Frequency speed-regulate )

Overall size  (m)(L×W×H)

7 X (2.3-4) X 1.8

Weight of equipment

4000~8000kg (approximately)

Chosen items (Should be ordered separately)

Embossment

Single embossment, double embossment, steel to steel embossment

Embossment down roller

Felt roller, paper roller, rubber roller

Jumbo roll stand

1-3 plies

Jumbo roll stand driving

Driven by variator

Rewinding unit

Non-core unit

Printing unit

Single color heliotype printing unit

Side rolling embossment

Steel to steel

Perforation mode

Air pneumatic separating unit

Smooth embossment

Steel to steel, Steel to rubber ;

Remote telecom service system

Should be ordered separately.
