Dual Core Embedded Mini IPC With Onboard Atom D525 CPU

Name: Dual Core Embedded Mini IPC With Onboard Atom D525 CPU
Brand: LingJiang
SKU: 103005947

US$ 1 - 600 MOQ: 1 Set

Key Specifications

Products Status:

Stock

Type:

Embedded Computer

Brand Name:

LingJiang

Shenzhen Ling Jiang Computer Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Type Embedded Computer

Brand Name LingJiang

Model Number Lbox-525

Place of Origin China

Specifications

1.Serial port: 1xRs-485/422/232 5xRs-232
2.Digital IOs: 1xVGA 2xRJ45
3.Operate Tem:-25-75 centigrade

System
Processor	On board Intel Atom D525
Chipset	Intel Atom D525 processor + Intel ICH8M
Memory	Supports 2 x 204-Pin SO-DIMM DDR3 memory slot, supporting Un-buffered Non ECC memory up to 8GB
Storage
IDE	1 x IDE
Serial ATA	2 x Serial ATA 300MB/S interface
Floppy	N/A
CF	1 x Compact Flash Socket Type I/II(front panel)
DOC/DOM	N/A
I/O Interface
USB	4 x USB2.0 MAX 8xUSB
Serial Port	6 x RS-232 (COM1 supports RS-232/422/485)
GPIO	4 x digital input,4 x digital output
Audio	HD Audio(Including Mic-in, Line-in, Line-out)
Display
Chipset	Intel Atom D525 Integrated 3150 Graphics
Resolution	VGA mode: up to 2048 x 1536 60Hz
Dual Display	VGA + LVDS
Ethernet
Chipset	1 x RTL8111D
Speed	2 x 10/100/1000Mbps
Connector	2 x RJ45
Mechanical and Environmental
Dimensions	210mm (L) x 125.8mm (W) x 60mm (H)
Operating Temperature	-20~75
Storage Temperature	-30~80
Operating Humidity	5 persent ~ 90persent (non-condensing)
Power
Power Supply	Supports +12V DC input or adapter with 220W DC input
Power Consumption	Power Consumption 18 W (Standby) .
Operating System
Windows OS	Windows2000/Windows XP/Windows 7
Embedded OS	Windows Xp
Test
Vibration	519Hz/1.0mm amplitude 19200Hz/1.0g acceleration
Shock	15g acceleration, 11ms duration
EMC/EMI	GB9254-20088 Class A
