Help CenterHeavy Pallet Rack
US$ 30 - 300
MOQ: 20 Sets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
XIANFU
Model Number:
HP031
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
XIANFU
Model Number
HP031
Type
Boltless / Rivet Shelving
Material
Steel
Feature
Corrosion Protection
Use
Warehouse Rack
Depth
2MM
Weight Capacity
1000-2000KGS
Width
1000MM
Height
4000
Specifications
Heavy pallet racks are suitable for those heavy goods. The height, width and loading capacity is adjustable.Some specifications for your reference:
| Heavy Pallet Rack Frames | ||
| Iter Lake Style 3"*1-5/8" upright Frame(inch) | Thickness(mm) | Weight(kg) |
| IU30*96 762*2440 | 1.9 | 17.76 |
| IU30*144 762*3660 | 1.9 | 26.09 |
| IU36*96 914*2440 | 1.9 | 19.38 |
| IU36*120 914*3050 | 1.9 | 22.93 |
| IU36*144 914*3660 | 1.9 | 28.32 |
| IU36*156 914*4000 | 1.9 | 31.58 |
| IU36*168 914*4270 | 1.9 | 32.50 |
| IU36*192 914*4880 | 1.9 | 34.45 |
| IU36*216 914*5490 | 1.9 | 39.80 |
| IU36*240 914*6100 | 1.9 | 43.42 |
| IU42*96 1067*2440 | 1.9 | 20.50 |
| IU42*120 1067*3050 | 1.9 | 23.95 |
| IU42*144 1067*3660 | 1.9 | 29.73 |
| IU42*156 1067*4000 | 1.9 | 33.50 |
| IU42*168 1068*4270 | 1.9 | 34.45 |
| IU42*180 1067*4570 | 1.9 | 35.80 |
| Iter Lake Style 3"*3" upright Frame(inch) | Thickness(mm) | Weight(kg) | ||
| IU18*360 475*9144 | 1.9 | 84.2(CU BRACE) | ||
| IU36*96 914*2440 | 1.9 | 27.05 | ||
| IU36*120 914*3050 | 1.9 | 33.07 | ||
| IU36*144 914*3660 | 1.9 | 37.85 | ||
| IU36*156 914*4000 | 1.9 | 40.8 | ||
| IU36*168 914*4270 | 1.9 | 44.2 | ||
| IU36*180 91484570 | 1.9 | 46.26 | ||
| IU36*192 914*4880 | 1.9 | 48.95 | ||
| IU36*216 914*5490 | 1.9 | 54.61 | ||
| IU36*240 914*6100 | 1.9 | 61.45 | ||
| IU36*336 914*8534 | 1.9 | 84.36 | ||
| IU36*384 914*9753 | 1.9 | 93.56 | ||
| IU36*240 914*6100 | 2.65 | 79.36 | ||
| IU42*96 1067*2440 | 1.9 | 28.43 | ||
| IU42*120 1067*3050 | 1.9 | 34.52 | ||
| IU42*144 1067*3660 | 1.9 | 39.20 | ||
| IU42*156 1067*4000 | 1.9 | 44.02 | ||
| IU42*168 1067*4270 | 1.9 | 46.77 | ||
| IU42*180 1067*4570 | 1.9 | 48.10 | ||
| IU42*192 1067*4880 | 1.9 | 50.30 | ||
| IU42*204 1067*5180 | 1.9 | 53.26 | ||
| IU42*216 1067*5490 | 1.9 | 56.11 | ||
| IU42*240 1067*6100 | 1.9 | 63.44 | ||
| IU42*252 1067*6400 | 1.9 | 66.83 | ||
| IU42*360 1067*9144 | 1.9 | 95.20(CU BRACE) | ||
| IU42*360 1067*9144 | 1.9 | 129.4(DOUBLE POST) | ||
| IU42*192 1067*4880 | 2.65 | 64.66 | ||
| IU42*240 1067*6100 | 2.65 | |||
| IU42*288 1067*7315 | 2.65 | 94.78 | ||
| IU42*300 1067*7620 | 2.65 | 97.50 | ||
| IU44*240 1118*6100 | 2.5 | 79.30 | ||
| IU48*96 1220*2440 | 1.9 | 29.93 | ||
| IU48*120 1220*3050 | 1.9 | 36.02 | ||
| IU48*144 1220*3660 | 1.9 | 42.03 | ||
| IU48*168 1220*4270 | 1.9 | 47.25 | ||
| IU48*180 1220*4570 | 1.9 | 50.05 | ||
| IU48*192 1220*4880 | 1.9 | 52.05 | ||
| IU48*216 1220*5490 | 1.9 | 57.66 | ||
| IU48*240 1220*6100 | 1.9 | 65.46 | ||
| IU48*276 1220*7010 | 1.9 | 73.68 | ||
| IU48*360 1220*9144 | 1.9 | 101(CU BRACE) | ||
| IU48*360 1220*9144 | 1.9 | 136.2(DOUBLE POST) | ||
| IU60*192 1524*4880 | 1.9 | 56.2 | ||
| IU60*192 1524*4880 | 2.65 | 70.2 | ||
| Pallet Rack Beams | ||
| Beam(INCH) | Thickness(mm) | Weight(kg) |
| IB4*96 102*2440 | 1.5 | 10.66 |
| IB4*108 102*2743 | 1.5 | 11.86 |
| IB4*120 102*3050 | 1.5 | 13.20 |
| IB4.5*96 115*2440 | 1.5 | 11.40 |
| IB4.5*108 115*2743 | 1.5 | 12.75 |
| IB4.5*120 115*3050 | 1.5 | 14.02 |
| IB4.5*144 115*3660 | 1.5 | 16.56 |
| IB5*96 127*2440 | 1.5 | 12.15 |
| IB5*108 127*2743 | 1.5 | 13.45 |
| IB5*120 127*3050 | 1.5 | 14.85 |
| IB5*132 127*3352 | 1.5 | 16.25 |
| IB5*144 127*3360 | 1.5 | 17.65 |
| IB5.5*96 140*2440 | 1.5 | 12.60 |
| IB5.5*108 140*2743 | 1.9 | 13.90 |
| IB5.5*120 140*3050 | 1.9 | 15.35 |
| IB5.5*132 140*3352 | 1.9 | 16.80 |
| IB5.5*144 140*3660 | 1.9 | 18.20 |
| IB5.5*156 140*3960 | 1.9 | 19.66 |
| IB6*96 153*2440 | 1.9 | 13.30 |
| IB6*108 152*2743 | 1.9 | 18.42 |
| IB6*120 152*3050 | 1.9 | 20.35 |
| IB6*132 152*3352 | 1.9 | 22.28 |
| IB6*144 152*3660 | 1.9 | 24.20 |
| IB6*156 152*3960 | 1.9 | 26.14 |
| IB6*168 152*4267 | 1.9 | 28.06 |
