Warehouse Racking

Name: Warehouse Racking
Brand: Xianfu
SKU: 102992225

US$ 80 - 120 MOQ: 50 Sets

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Xianfu

Use:

Warehouse Rack

Ningbo Xianfu Metal Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Xianfu

Use Warehouse Rack

Specifications

Feature: 1.Loading capacity: 500kgs -3500kgs;2.Material:steel; 3. Powder coating & spray painting;4. All size available

Features:	Beam levers are adjustable in 75mm pitch interval. Different sizes, various specifications and colors are available according to customers’ different needs. Maximizes space use ratio in any warehouse configuration while retaining optimum product accessibility. Strength and rigidity prevents compression damage to goods. Bottom level of pallets can be stored on the floor, lowering structure costs.
Load Capacity & Dimension:	Loading capacity: 500-2500 kgs UDL/beam level. Height: 1000-10000mm Depth: 400-1500mm Length: 1500-3600mm Specail sizes also avaiable to specific storage needs.
Main Parts Specs:	Uprights:80x60x2.0, 90x70x2.0, 100x70*2.0, 120x95x2.0, 120x95x2.5 Box beams: 80x50x1.5, 100x50x1.5, 120x50x1.5, 140x50x1.5, 160x50x1.5 Horizontal & diagonal braces, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components.
Material:	High grade Q235B Steel
Finish:	High quality Powder Coating Finishing.
