Computerized Numerical Control (CNC) Buffer FMP

Specifications

Computerized Numerical Control/ CNC Buffer FMP is used to buff the tyres, especially aircraft tyres in cold retreading mostly.

Function:

Computerized Numerical Control/ CNC Buffer FMP is used to buff the tyres, especially aircraft tyres in cold retreading mostly. The whole buffing process is controlled by computer to make sure buffing precision.





Features:

1. Computer numerical control mechanism, buffing automatically (cutting first) with high productivity and energy efficiency.
2. Automatical centering system, easy and precise.
3. Buffing any required curves on the under-tread, shoulders and sidewalls.
4. Thousands of buffing programs can be stored in the computer.
5. The spindle is driven by friction control, guarantee the uniform roughness of the under-tread surface.
6. The cooling system of grinding wheel lengthens its working life significantly.
7. Equipped with an alarm device, alarming when the cutter worn out.
8. With rotary encoder, measure the circumference of buffing tyre precisely.
9. Buffing programs and data are stored. With an interface module for informatization management.



Specifications:

Model	FMP
Size Range	7.50R16~12.00R20
Dimension(mm)	3000×2000×2300
Electric machine power(kw)	23
Power supply	AC380V,AC220V,50HZ
Compressed air source(mpa)	0.8
