Specifications
1kw horizontal axis wind turbine,mini permanent magnet generator1. Easy to start up.
2. Low noise.
3. Ce approved
Hot selling Wind turbine residential 1000w HAWT wind power generator
Detailed Product Description:
1.Low speed permanent magnet generator
2.Low starting torque,High generating efficiency
3.Glassfibre high efficiency blades.
4.Neodymium magnets and bearing with high performance
5.Yaw motor system
6.Designed for minimal maintenance and easy install
7.Aerodynamic brake & manul brake.
8.The span life of our products is 20~25 years .
Company Introduce:
Qingdao Richuan Precision Machinery Co., Ltd. Is a well-known wind tubine generator manufacturer. It is a high-tech entity, which devotes to researching and developing the most advanced direct drive wind solar system with the best quality.
Our RC series wind power generating set utilize a new aerofoil vertical axis wind wheel and magnetic suspention structure,the high wind energy coefficient,very low start-up wind speed, the high anti-wind capability,high stability,anti-corosion,no noise,maintenace free and long service life .
Detailed Product Parameter:
| 1KW Horizontal axis Wind Turbine Generator On-grid | |
| Power | 1000W |
| Type of generator | Permanent-magnet 48vA.C. |
| Blade diameter: | 3.0m |
| Blade Material: | FRP (Fiber glass reinforced*3) |
| Rated rotor speed | 360r/min |
| Rated speed | 8m/s |
| Rated Power | 1000W |
| Max Power | 1500w |
| Output voltage | 48v |
| Start up wind speed | 3(m/s) |
| Work speed | 3-25(m/s) |
| Security wind speed | 40(m/s) |
| Height of guy cable tower | 6m |
| Top quality except tower | 83kg |
| Total weight(kg) | 170kg |
| Output controller system | Controller , Inverter |
| Can supply power for | refrigerator, washing machine , water pump , color TV, lighter, fanner, charger |
| 1KW Horizontal axis Wind Turbine Generator Off-grid | |
| Power | 1000W |
| Type of generator | Permanent-magnet 48vA.C. |
| Blade diameter: | 3.0m |
| Blade Material: | FRP (Fiber glass reinforced*3) |
| Rated rotor speed | 360r/min |
| Rated speed | 8m/s |
| Rated Power | 1000W |
| Max Power | 1500w |
| Output voltage | 48v |
| Start up wind speed | 3(m/s) |
| Work speed | 3-25(m/s) |
| Security wind speed | 40(m/s) |
| Height of guy cable tower | 6m |
| Top quality except tower | 83kg |
| Total weight(kg) | 170kg |
| Output controller system | Controller , Inverter |
| Can supply power for | refrigerator, washing machine , water pump , color TV, lighter, fanner, charger |
Note:
1. Tower type and tower height can be changed as per your request.
2. Working voltage can be special requested.
3. For the details,please feel free to contact us.
Main Markets:
High quality and competitive price guarantee us a huge market all over the world, such as in Eastern Asia, Europe, North America ,South America and Middle East.
Wind Turbine Generator Control Systerm:
Pictures for your referance:
