*Radiator 40°C max, fans are driven by belt, with safety guard
*12//24V DC start motor and storage battery
*Brushless, self-excited, IP22/23, insulation H alternator
*Absorber to reduce vibration
*Dry type air filter, fuel filter, oil filter
*Main line circuit breaker
*Control system: Key start control panel as standard, digital auto start or ATS system is optional
*8 hours operation base fuel tank
*High efficient muffler to reduce noise
*Ripple flex exhaust pipe, exhaust siphon and flange etc.
*Genset type: open type or soundproof/silent type, or trailer type
* Maintenance and operation manual, quality certificate, etc.
*Rigorous testing must be done before delivery, including 50% load, 75%load, 100%load, 110%
and all protection function(over speed stop, high water temperature, low oil pressure, battery
charging fail, emergency stop)
MAIN TECHNICAL DATA SHEET
GENERATOR SET | |
Genset model |
GF-50 |
Prime power (KW/KVA) |
90/112.5 |
Standby power (KW/KVA) |
108/135 |
Frequency & voltage |
230/400V, 50HZ |
No. of Phase |
3 |
Genset type |
Silent/Sound proof |
|
Reference Dimension & Weight (W*H, mm)/KGS |
2550*1100*1800,1250KGS |
DIESEL ENGINE | |
Engine brand & Model |
HUAFA, HFR6105ZD |
Rated output |
90KW |
Rated Speed |
1500RPM |
Engine Type |
Four stork, in-line water cooled |
No. of cylinder |
4 |
Bore*stroke |
105*125mm |
Aspiration method |
Trubocharged |
Governor |
Mechanical |
Starting method |
Electric starting |
Cooling method |
Forced water cooled |
Lubrication method |
Pressure & splash lubricating |
Fuel consumption |
258g/kw.h |
ALTERNATOR | |
Alternator brand & model |
Stamford/Leroy Somer/China reputed one |
Type |
Brushless & self-excited |
No. of phase |
3 |
Volatage |
230/400v |
Frequency |
50HZ |
Power Factor |
0.8 |
Insulation Grade |
H |
Protection Grade |
IP22/23 |
Altitude |
≤1000m |
|
|
|
|
|
|
|
|
|
